端边云协同的氧化铝生产过程苛性碱浓度智能预报方法

高愫婷; 柴天佑

doi:10.16383/j.aas.c220227

端边云协同的氧化铝生产过程苛性碱浓度智能预报方法

doi: 10.16383/j.aas.c220227

高愫婷^1,,
柴天佑^{1, 2,}

1.
东北大学流程工业综合自动化国家重点实验室沈阳 110819
2.
国家冶金自动化工程技术研究中心沈阳 110819

基金项目: 2020年度辽宁省科技重大专项计划 (2020JH1/10100008), 国家自然科学基金委重大项目(61991404, 61991400), 一体化过程控制学科创新引智基地 2.0 (B08015) 资助

详细信息

作者简介:
高愫婷：东北大学流程工业综合自动化国家重点实验室博士研究生. 主要研究方向为复杂工业过程关键生产指标测量方法. E-mail: 2110266@stu.neu.edu.cn

柴天佑：中国工程院院士, 东北大学教授. IEEE Life Fellow, IFAC Fel-low, 欧亚科学院院士. 主要研究方向为自适应控制, 智能解耦控制, 流程工业综合自动化与智能化系统理论、方法与技术. 本文通信作者. E-mail: tychai@mail.neu.edu.cn

计量
- 文章访问数: 1046
- HTML全文浏览量: 390
- PDF下载量: 355
- 被引次数: 0
出版历程
- 收稿日期: 2022-03-29
- 录用日期: 2022-06-22
- 网络出版日期: 2022-07-31
- 刊出日期: 2023-05-20

Intelligent Forecasting Method of Caustic Concentration in Alumina Production Process Based on End-edge-cloud Coordination

GAO Su-Ting^1
,,
CHAI Tian-You^{1, 2
,}

1.
State Key Laboratory of Synthetical Automation for Process Industries, Northeastern University, Shenyang 110819
2.
National Engineering Research Center of Metallurgy Automation, Shenyang 110819

Funds: Supported by Science and Technology Major Project 2020 of Liaoning Province (2020JH1/10100008), National Natural Science Foundation of China (61991404, 61991400), and 111 Project 2.0 (B08015)

More Information

Author Bio:
GAO Su-Ting　Ph.D. candidate at the State Key Laboratory of Synthetical Automation for Process Industries, Northeastern University. Her main research interest is measuring method of key production index in complex industrial process

CHAI Tian-You　Academician of Chinese Academy of Engineering, professor at Northeastern University, IEEE Life Fellow, IFAC Fellow, and academician of the International Eurasian Academy of Sciences. His research interest covers adaptive control, intelligent de-coupling control, and theories, methods and techno-logy of synthetical automation and intelligent system for process industries. Corresponding author of this paper

摘要

摘要: 苛性碱溶液浓度是氧化铝生产过程中的重要运行指标, 由于苛性碱溶液的温度和浓度频繁波动, 导致目前的浓度检测仪表检测精度低, 只能采用人工化验获得苛性碱浓度值, 化验结果的严重滞后导致无法实现苛性碱浓度的自动控制, 影响氧化铝产品质量. 在分析苛性碱溶液浓度控制过程动态特性的基础上建立了由线性模型和未知非线性动态系统描述的苛性碱浓度预报模型, 将参数辨识与自适应深度学习相结合, 提出端边云协同的氧化铝生产过程苛性碱浓度智能预报方法, 并采用氧化铝生产企业的实际生产数据对本文所提方法进行应用验证. 应用结果表明, 所提的苛性碱浓度智能预报方法可以实时、准确预报苛性碱浓度, 为实现苛性碱浓度的闭环运行优化控制创造了条件.
- 苛性碱浓度 /
- 未知非线性动态系统 /
- 端边云 /
- 自适应深度学习 /
- 长短周期记忆
Abstract: Caustic concentration is an important operating indicator in alumina production process. Due to frequent fluctuations in terms of the temperature and concentration of caustic solution, the precision of current concentration meters can not be guaranteed. High precision caustic concentration can only be obtained through manual assay. However, the severe lag of assay results will lead to the failure of automatic control of caustic concentration, which affects the quality of alumina products. In this paper, the dynamic characteristics of caustic concentration are analysed, and a caustic concentration forecasting model described by a linear model and an unknown nonlinear dynamic system is established. Then a novel intelligent forecasting method for caustic concentration of alumina production process based on end-edge-cloud cooperation is established by incorporating parameter identification with adaptive deep learning. The application verification of the proposed method is performed on actual production data from an alumina manufacturer. The results show that the proposed intelligent forecasting method is able to forecast caustic concentration accurately in real time, providing conditions for achieving the closed-loop optimal control of caustic concentration.
- Caustic concentration /
- unknown nonlinear dynamic system /
- end-edge-cloud /
- adaptive deep learning /
- long-short term memory (LSTM)

HTML全文

图 1 苛性碱浓度运行控制流程图

Fig. 1 Operation and control chart of caustic concentration

下载: 全尺寸图片幻灯片

图 2 端边云协同的苛性碱浓度智能预报结构

Fig. 2 Intelligent forecasting structure of caustic concentration based on end-edge-cloud coordination

下载: 全尺寸图片幻灯片

图 3 $ \bar{v}(k) $深度学习模型结构

Fig. 3 Deep learning model structure of $ \bar{v}(k) $

下载: 全尺寸图片幻灯片

图 4 验证误差MAE与$ n $的曲线

Fig. 4 Validation MAE and $ n $

下载: 全尺寸图片幻灯片

图 5 验证误差MAE与$ \bar{h} $的曲线

Fig. 5 Validation MAE and $ \bar{h} $

下载: 全尺寸图片幻灯片

图 6 验证误差MAE与$ N $的曲线

Fig. 6 Validation MAE and $ N $

下载: 全尺寸图片幻灯片

图 7 苛性碱浓度预报方法实验结果

Fig. 7 Experimental results of caustic concentration forecasting method

下载: 全尺寸图片幻灯片

表 1 验证误差与深度神经网络中LSTM单元层数

Table 1 Validation error and the number of LSTM unit

LSTM单元层数	1	2	3	4
RMSE	1.28	1.14	1.17	1.20
MAE	1.00	0.82	0.83	0.91
MAPE	0.53	0.47	0.48	0.51

下载: 导出CSV

表 2 $ TP $、$ FP $、$ TN $和$ FN $的计算方式

Table 2 Formula of $ TP $, $ FP $, $ TN $ and $ FN $

条件	$ \bar{v}(k) - \bar{v}(k - 1)\geq0 $	$ \bar{v}(k) - \bar{v}(k - 1)<0 $
$ \hat{\bar{v}}(k) - \hat{\bar{v}}(k - 1)\geq 0 $	$ TP(k)=1 $	$ FN(k)=1 $
$ \hat{\bar{v}}(k) - \hat{\bar{v}}(k - 1)< 0 $	$ FP(k)=1 $	$ TN(k)=1 $

下载: 导出CSV

表 3 苛性碱浓度预报效果

Table 3 Forecasting result for caustic concentration

方法	RMSE	MAE
本文方法	0.89	0.58
线性模型	2.76	2.21
深度学习模型	1.21	0.97

下载: 导出CSV

表 4 苛性碱浓度预报方法的精度指标

Table 4 Accuracy index of forecasting method for caustic concentration

方法	RMSE	MAE	TPR (%)	TNR (%)
浓度检测仪表	6.87	6.38	55.17	63.64
离线预报模型	1.14	0.82	76.04	92.86
在线预报模型	0.94	0.67	84.38	93.85
本文方法	0.89	0.58	88.54	94.05

下载: 导出CSV
