基于灵活平衡约束的图聚类方法

罗辉; 韩纪庆

doi:10.16383/j.aas.c200144

基于灵活平衡约束的图聚类方法

doi: 10.16383/j.aas.c200144

罗辉^1,,
韩纪庆^1,

1.
哈尔滨工业大学计算机科学与技术学院哈尔滨 150001

基金项目: 国家自然科学基金(U1736210), 国家重点研发计划(2017YFB1002102)资助

详细信息

作者简介:
罗辉：哈尔滨工业大学计算机科学与技术学院博士研究生. 2014年获贵州大学通信与信息系统专业硕士学位. 主要研究方向为智能语音处理技术和模式识别. 本文通信作者.E-mail: luohui0216@163.com

韩纪庆：哈尔滨工业大学计算机科学与技术学院教授. 1998年获哈尔滨工业大学计算机科学博士学位. 主要研究方向为智能语音处理技术和音频信息的智能处理. E-mail: jqhan@hit.edu.cn

计量
- 文章访问数: 1095
- HTML全文浏览量: 316
- PDF下载量: 156
- 被引次数: 0
出版历程
- 收稿日期: 2020-03-18
- 录用日期: 2020-08-14
- 网络出版日期: 2020-12-17
- 刊出日期: 2023-04-20

Graph Clustering Based on Flexibly Balanced Constraint

LUO Hui^1
,,
HAN Ji-Qing^1
,

1.
School of Computer Science and Technology, Harbin Institute of Technology, Harbin 150001

Funds: Supported by National Natural Science Foundation of China (U1736210) and National Key Research and Development Program of China (2017YFB1002102)

More Information

Author Bio:
LUO Hui　Ph.D. candidate at the School of Computer Science and Technology, Harbin Institute of Technology. He received his master degree in communication and information systems from Guizhou University in 2014. His research interest covers intelligent speech processing technology and pattern recognition. Corresponding author of this paper

HAN Ji-Qing　Professor at the School of Computer Science and Technology, Harbin Institute of Technology. He received his Ph.D. degree in computer science from Harbin Institute of Technology in 1998. His research interest covers intelligent speech processing technology and intelligent processing of audio information

摘要

摘要: 现有的图聚类方法主要存在两方面的问题, 一是对各个类规模一致的假设, 在许多实际应用中并不成立; 二是在处理多类聚类问题时, 其所常借助的递归技术或启发式算法会影响聚类的性能. 为此, 本文提出一种基于灵活平衡约束的多类图聚类方法. 其能够覆盖从绝对平衡约束到无平衡约束的范围, 可同时处理类别规模一致和不一致的问题. 为有效求解新方法中的参数, 进一步提出一个紧松弛方法来使所提出的图聚类方法不仅易于求解, 且在处理多类聚类问题时不必依赖递归技术, 而能直接得到聚类结果. 另外, 本文还给出一种实现松弛图聚类的有效求解算法. 在合成数据和真实数据上的实验结果表明, 所提出的方法具有良好的性能.
- 图聚类 /
- 图分割 /
- 平衡约束 /
- 紧松弛
Abstract: The existing graph clustering methods suffer from two main problems: first, they assume that the size of each class is the same, which is not applicable in many practical applications; second, when dealing with multi-class clustering problems, the recursive technique or heuristic algorithm that is commonly used can affect the clustering performance. To address these issues, this paper proposes a multi-class graph clustering method based on flexible balance constraints. It can cover a range from absolute balance constraints to no balance constraints and can handle both uniform and non-uniform class size problems simultaneously. To effectively solve the parameters in the new method, a tight relaxation method is further proposed to make the proposed graph clustering method not only easy to solve but also able to obtain clustering results directly without relying on recursive techniques when dealing with multi-class clustering problems. In addition, this paper also presents an effective algorithm for implementing the relaxed graph clustering. Experimental results on both synthetic and real data demonstrate that the proposed method has good performance.
- Graph clustering /
- graph cut /
- balanced constraint /
- tight relaxation

HTML全文

图 1 函数$\Phi_p(v)$在不同参数$p$时的示意图^[14]

Fig. 1 Illustration of functions $\Phi_p(v)$ with different parameter $p$^[14]

下载: 全尺寸图片幻灯片

图 2 函数$\Psi_r(v)$在不同参数$r$时的示意图

Fig. 2 Illustration of functions $\Psi_r(v)$ with different parameter $r$

下载: 全尺寸图片幻灯片

图 3 函数$\widehat{W}$和$\widehat{G}$的对比图

Fig. 3 The comparisons of $\widehat{W}$ and $\widehat{G}$

下载: 全尺寸图片幻灯片

图 4 合成数据及其邻接图

Fig. 4 Synthetic data and its adjacency graph

下载: 全尺寸图片幻灯片

图 5 Ratio形式的图聚类结果

Fig. 5 Results of Ratio graph clustering methods

下载: 全尺寸图片幻灯片

图 6 Normalized形式的图聚类结果

Fig. 6 Results of Normalized graph clustering methods

下载: 全尺寸图片幻灯片

图 7 聚类结果的统计分析

Fig. 7 Statistical analysis of clustering results

下载: 全尺寸图片幻灯片

表 1 真实数据集

Table 1 The statistics of real databases

数据集	样本数	类别数	数据类型
HIGHSCHOOL	60	5	社交
POLBOOKS	105	3	社交
FOOTBALL	115	12	社交
DUKE	44	2	医疗
CANCER	198	14	医疗
KHAN	83	4	基因
ROSETTA	300	5	基因
ORL	400	40	图像
UMIST	575	20	图像
ALPHADIGS	1404	36	图像
COIL20	1440	20	图像
SAVEE	480	7	语音
CASIA	1200	6	语音
IEMOCAP	9994	8	语音
MED	1033	31	文本
WEBKB4	4196	4	文本
REUTERS	8293	65	文本
YEAST	1484	10	生物
FAULTS	1941	7	工业
ECOLI	327	5	蛋白质

下载: 导出CSV

表 2 各图聚类方法的聚类精度(%)对比

Table 2 Comparison of clustering accuracies (%) between graph clustering methods

数据集	1Spec^[16]	MTV^[11]	L21MC^[19]	BKCut^[18]	CCB^[15]	FBC (r)	FMC (r)
HIGHSCHOOL	81.67	80.00	70.00	81.67	86.67	71.67 (0.9)	89.67 (1.2)
POLBOOKS	82.86	79.05	77.14	81.90	83.81	81.50 (1.4)	83.81 (1.3)
FOOTBALL	86.96	92.17	24.35	93.04	86.09	92.11 (1.3)	93.04 (1.8)
DUKE	52.27	70.45	63.64	52.27	52.27	70.45 (0.5)	70.45 (0.5)
CANCER	34.34	54.04	52.02	54.55	48.48	53.54 (1.5)	54.55 (1.7)
KHAN	57.83	49.40	54.22	51.81	57.83	50.28 (1.6)	57.83 (1.6)
ROSETTA	76.67	76.67	76.67	76.67	76.67	76.67 (1.0)	77.33 (1.9)
ORL	36.00	52.50	79.25	82.00	74.25	74.75 (1.5)	81.75 (1.0)
UMIST	58.96	76.87	70.78	70.09	65.22	72.70 (1.3)	74.96 (1.3)
ALPHADIGS	36.11	51.71	46.08	47.72	45.87	36.84 (2.0)	49.00 (2.0)
COIL20	45.00	81.46	50.97	78.89	77.29	81.81 (1.0)	82.92 (1.2)
SAVEE	25.21	32.50	31.46	31.46	29.17	31.02 (1.1)	33.24 (1.3)
CASIA	22.42	32.92	28.50	28.08	28.58	26.00 (0.1)	35.54 (0.4)
IEMOCAP	54.03	54.00	54.00	54.03	54.03	54.03 (1.9)	55.21 (1.5)
MED	44.72	53.92	52.76	54.99	53.53	50.09 (1.4)	55.00 (1.4)
WEBKB4	39.39	56.22	39.30	51.60	39.56	46.14 (0.5)	59.60 (0.7)
REUTERS	52.83	73.34	65.69	61.02	69.38	67.58 (2.0)	73.53 (1.5)
YEAST	51.35	53.97	49.26	53.71	51.95	44.41 (1.6)	54.85 (1.6)
FAULTS	36.89	40.08	37.92	41.11	39.52	31.72 (1.8)	42.76 (1.7)
ECOLI	79.82	77.67	77.67	82.87	77.98	71.43 (1.8)	82.87 (1.8)

下载: 导出CSV

表 3 本文方法与其他非图聚类方法的聚类精度(%)对比

Table 3 Comparison of clustering accuracies (%) between ours and other non-graph clustering methods

数据集	PNMF^[44]	NSC^[45]	PLSI^[42]	LSD^[46]	NMFR^[47]	CLR^[43]	FMC (r)
HIGHSCHOOL	81.67	83.33	83.33	81.67	95.00	80.00	89.67 (1.2)
POLBOOKS	78.10	80.95	78.10	78.10	79.05	80.95	83.81 (1.3)
FOOTBALL	93.04	93.04	93.04	93.04	93.04	93.04	93.04 (1.8)
DUKE	52.27	52.27	70.45	70.45	70.45	52.27	70.45 (0.5)
CANCER	53.53	53.03	53.53	53.03	51.52	54.04	54.55 (1.7)
KHAN	60.24	55.42	55.42	51.81	50.60	51.81	57.83 (1.6)
ROSETTA	76.67	76.67	76.67	76.67	76.67	77.00	77.33 (1.9)
ORL	81.50	82.25	82.50	81.25	82.50	80.00	81.75 (1.0)
UMIST	64.00	68.00	68.52	68.35	71.83	70.26	74.96 (1.3)
ALPHADIGS	44.94	49.43	48.65	49.36	50.78	36.47	49.00 (2.0)
COIL20	75.21	81.25	80.69	75.00	82.85	85.21	82.92 (1.2)
SAVEE	31.88	31.46	31.67	34.17	31.88	28.13	33.24 (1.3)
CASIA	35.17	29.08	32.00	32.17	34.08	27.92	35.54 (0.4)
IEMOCAP	54.00	54.06	54.00	54.00	54.00	54.02	55.21 (1.5)
MED	53.92	53.73	54.50	54.60	55.86	49.18	55.00 (1.4)
WEBKB4	39.06	39.77	48.90	50.81	63.32	39.56	59.60 (0.7)
REUTERS	73.86	76.47	75.92	74.99	76.52	51.80	73.53 (1.5)
YEAST	52.76	54.31	52.69	52.09	54.85	46.90	54.85 (1.6)
FAULTS	39.26	40.08	40.03	40.18	38.17	41.37	42.76 (1.7)
ECOLI	77.68	78.90	79.82	67.89	79.20	78.29	82.87 (1.8)

下载: 导出CSV

表 4 不同聚类方法得到的图分割函数值

Table 4 The values of different graph cut functions obtained by different clustering methods

图分割函数	1Spec^[16]	MTV^[11]	L21MC^[19]	BKCut^[18]	CCB^[15]	PLSI^[42]	LSD^[46]	NMFR^[47]	CLR^[43]	本文方法
FRCut_0.5	12.64 (13.01)	13.99 (12.66)	15.57 (10.64)	12.03 (11.09)	18.63 (14.63)	14.43 (12.16)	14.70 (12.41)	14.27 (12.04)	13.69 (12.14)	9.71 (10.52)
FRCut_1.0	9.21 (9.64)	12.27 (11.22)	12.09 (8.27)	9.67 (9.31)	13.93 (11.28)	12.36 (10.35)	12.95 (10.83)	12.77 (10.90)	9.78 (9.08)	8.05 (8.18)
FRCut_2.0	7.79 (7.96)	11.89 (10.99)	10.90 (7.77)	8.37 (8.42)	12.18 (10.64)	11.88 (9.99)	12.62 (10.57)	12.50 (10.78)	8.18 (8.36)	6.72 (7.18)
FNCut_0.5	1.83 (1.48)	1.78 (1.42)	2.05 (1.25)	1.57 (1.25)	1.87 (1.46)	1.84 (1.35)	1.90 (1.38)	1.83 (1.37)	1.79 (1.48)	1.39 (1.21)
FNCut_1.0	1.35 (1.14)	1.53 (1.23)	1.56 (0.93)	1.29 (1.09)	1.41 (1.13)	1.54 (1.14)	1.63 (1.18)	1.60 (1.20)	1.26 (1.06)	1.14 (1.03)
FNCut_2.0	1.19 (1.00)	1.47 (1.20)	1.39 (0.87)	1.18 (1.03)	1.24 (1.07)	1.47 (1.10)	1.57 (1.14)	1.55 (1.17)	1.04 (0.95)	0.92 (0.83)

下载: 导出CSV
