基于上下文和浅层空间编解码网络的图像语义分割方法

罗会兰; 黎宵

doi:10.16383/j.aas.c190372

基于上下文和浅层空间编解码网络的图像语义分割方法

doi: 10.16383/j.aas.c190372

罗会兰^1,,
黎宵^1,

1.
江西理工大学信息工程学院赣州 341000

基金项目: 国家自然科学基金(61862031, 61462035), 江西省自然科学基金(20171BAB202014), 江西省主要学科学术和技术带头人培养计划 (20213BCJ22004)资助

详细信息

作者简介:
罗会兰：江西理工大学信息工程学院教授. 2008年获浙江大学计算机科学与技术博士学位. 主要研究方向为计算机视觉与机器学习. 本文通信作者. E-mail: luohuilan@sina.com

黎宵：江西理工大学信息工程学院硕士研究生. 主要研究方向为计算机视觉与语义分割. E-mail: williamlixiao@sina.com

计量
- 文章访问数: 833
- HTML全文浏览量: 189
- PDF下载量: 249
- 被引次数: 0
出版历程
- 收稿日期: 2019-05-15
- 录用日期: 2019-10-11
- 网络出版日期: 2022-06-16
- 刊出日期: 2022-07-01

Image Semantic Segmentation Method Based on Context and Shallow Space Encoder-decoder Network

LUO Hui-Lan^1
,,
LI Xiao^1
,

1.
School of Information Engineering, Jiangxi University of Science and Technology, Ganzhou 341000

Funds: Supported by National Natural Science Foundation of China (61862031, 61462035), Natural Science Foundation of Jiangxi Pro-vince (20171BAB202014), and Training Plan for Academic and Technical Leaders of Major Disciplines in Jiangxi Province (20213BCJ22004 )

More Information

Author Bio:
LUO Hui-Lan　Professor at the School of Information Engineering, Jiangxi University of Science and Technology. She received her Ph.D. degree in computer science and technology from Zhejiang University in 2008. Her research interest covers computer vision and machine learning. Corresponding author of this paper

LI Xiao　Master student at the School of Information Engineering, Jiangxi University of Science and Technology. His research interest covers computer vision and semantic segmentation

摘要

摘要: 当前图像语义分割研究基本围绕如何提取有效的语义上下文信息和还原空间细节信息两个因素来设计更有效算法. 现有的语义分割模型, 有的采用全卷积网络结构以获取有效的语义上下文信息, 而忽视了网络浅层的空间细节信息; 有的采用U型结构, 通过复杂的网络连接利用编码端的空间细节信息, 但没有获取高质量的语义上下文特征. 针对此问题, 本文提出了一种新的基于上下文和浅层空间编解码网络的语义分割解决方案. 在编码端, 采用二分支策略, 其中上下文分支设计了一个新的语义上下文模块来获取高质量的语义上下文信息, 而空间分支设计成反U型结构, 并结合链式反置残差模块, 在保留空间细节信息的同时提升语义信息. 在解码端, 本文设计了优化模块对融合后的上下文信息与空间信息进一步优化. 所提出的方法在3个基准数据集CamVid、SUN RGB-D和Cityscapes上取得了有竞争力的结果.
- 语义分割 /
- 二分支策略 /
- 语义上下文信息 /
- 浅层空间细节信息 /
- 反U型结构
Abstract: Recently, the research on image semantic segmentation basically focuses on how to extract effective semantic context information and restore spatial information in order to get more efficient algorithms. Some models use a fully convolutional network structure to obtain effective semantic context information. This kind of framework does not use the spatial details in the shallow layers of the networks. To effectively restore the spatial details for the decoder, some researches utilize the U-shape structure of complex network connections. But they could not obtain high-quality semantic context features. To better combine context information and space information, a novel semantic segmentation framework is proposed in this paper. A two-branch strategy is adopted on the encoder. One branch is called contextual branch, which is constructed with a proposed semantic context module to obtain high-quality semantic context information. And the other branch is spatial branch, which is designed as an inverse U-shaped structure with the proposed chain-reverse residual module to enhance semantic information and preserve spatial details. Moreover, a refinement module is proposed to add to the decoder to further refine the fusion features of context information and spatial information. The proposed approach achieves competitive results on the CamVid, SUN RGB-D and Cityscapes benchmarks.
- Semantic segmentation /
- two-branch strategy /
- context semantic information /
- shallow space details /
- inverse U-shaped structure

HTML全文

图 1 本文提出的网络结构与其他网络结构

Fig. 1 The network structures of our method and other methods

下载: 全尺寸图片幻灯片

图 2 本文网络框架(HAB: 混合扩张卷积模块; RPB: 残差金字塔特征提取模块; CRB: 链式残差模块;RRB: 残差循环卷积模块; Deconv: 转置卷积; R: 扩张率)

Fig. 2 The network framework of our method (HAB: hybrid atrous convolution block; RPB: residual pyramid feature block; CRB: chain inverted residual block; RRB: residual recurrent convolution block; Deconv: transposed convolution; R: atrous rate)

下载: 全尺寸图片幻灯片

图 3 ResNet-34骨干网络结构

Fig. 3 The backbone structure of ResNet-34

下载: 全尺寸图片幻灯片

图 4 3种不同扩张率的扩张卷积, 从左到右分别为r = 1, 3, 4

Fig. 4 Illustrations of the atrous convolution with three different atrous rates, r = 1, 3, 4

下载: 全尺寸图片幻灯片

图 5 混合扩张卷积模块

Fig. 5 Hybrid atrous convolution block

下载: 全尺寸图片幻灯片

图 6 残差金字塔特征提取模块

Fig. 6 Residual pyramid feature block

下载: 全尺寸图片幻灯片

图 7 链式反置残差模块

Fig. 7 Chain inverted residual block

下载: 全尺寸图片幻灯片

图 8 残差循环卷积模块

Fig. 8 Residual recurrent convolution block

下载: 全尺寸图片幻灯片

图 9 在Camvid测试集上本文方法与SegNet^[12]、CGNet^[23]和BiSeNet (xception)^[14]方法的定性比较

Fig. 9 Qualitative comparisons with SegNet^[12], CGNet^[23] and BiSeNet (xception)^[14] on the CamVid test set

下载: 全尺寸图片幻灯片

图 10 本文方法在SUN RGB-D测试集上的定性结果

Fig. 10 Qualitative results of our method on the SUN RGB-D test set

下载: 全尺寸图片幻灯片

图 11 本文方法在Cityscapes验证集上的定性结果

Fig. 11 Qualitative results of our method on the Cityscapes val set

下载: 全尺寸图片幻灯片

表 1 本文方法与其他方法在CamVid测试集上的MIoU比较(%)

Table 1 Comparison of MIoU between our method and the state-of-the-art methods on the CamVid test set (%)

方法	Tree	Sky	Building	Car	Sign	Road	Pedestrian	Fence	Pole	Sidewalk	Bicyclist	MIoU
FCN-8^[1]	−	−	−	−	−	−	−	−	−	−	−	52.0
DeconvNet^[8]	−	−	−	−	−	−	−	−	−	−	−	48.9
SegNet^[12]	52.0	87.0	68.7	58.5	13.4	86.2	25.3	17.9	16.0	60.5	24.8	50.2
ENet^[7]	77.8	95.1	74.7	82.4	51.0	95.1	67.2	51.7	35.4	86.7	34.1	51.3
Dilation^[2]	76.2	89.9	82.6	84.0	46.9	92.2	56.3	35.8	23.4	75.3	55.5	65.29
LRN^[10]	73.6	76.4	78.6	75.2	40.1	91.7	43.5	41.0	30.4	80.1	46.5	61.7
FC-DenseNet103^[11]	77.3	93.0	83.0	77.3	43.9	94.5	59.6	37.1	37.8	82.2	50.5	66.9
G-FRNet^[18]	76.8	92.1	82.5	81.8	43.0	94.5	54.6	47.1	33.4	82.3	59.4	68.0
BiSeNet (xception)^[14]	74.4	91.9	82.2	80.8	42.8	93.3	53.8	49.7	31.9	81.4	54.0	65.6
CGNet^[23]	−	−	−	−	−	−	−	−	−	−	−	65.6
本文方法	75.8	92.4	81.9	82.2	43.3	94.3	59.0	42.3	37.3	80.2	61.3	68.26

下载: 导出CSV

表 2 在CamVid数据集上的性能比较

Table 2 Performance comparisons of our method and the state-of-the-art methods on the CamVid dataset

方法	参数量 (MB)	运行时间 (ms)	帧速率 (帧/s)	MIoU (%)
SegNet^[12]	29	23.2	42	50.2
BiSeNet (xception)^[14]	5.8	12.1	82	65.6
BiSeNet (ResNet18)^[14]	49	64.8	15	68.7
本文方法	31	39.5	25	68.26

下载: 导出CSV

表 3 本文方法与其他方法在SUN RGB-D测试集上的MIoU比较 (%)

Table 3 Comparison of MIoU between our method and the state-of-the-art methods on the SUN RGB-D test set (%)

方法	MIoU
FCN-8^[1]	27.4
DeconvNet^[8]	22.6
ENet^[7]	19.7
SegNet^[12]	31.8
DeepLab^[4]	32.1
本文方法	40.79

下载: 导出CSV

表 4 本文方法与其他方法在Cityscapes测试集上的比较

Table 4 Comparisons of our method with the state-of-the-art methods on the Cityscapes test set

方法	参数量 (MB)	MIoU (%)
FCN-8^[1]	134.5	65.3
ENet^[7]	0.4	58.3
SegNet^[12]	29.5	56.1
DeepLab^[4]	44.04	70.4
Dilation^[2]	−	67.1
PSPNet^[5]	65.7	78.4
CGNet^[23]	0.5	64.8
BiSeNet (xception)^[14]	5.8	68.4
BiSeNet (ResNet18)^[14]	49	74.7
本文方法	31	73.1

下载: 导出CSV

表 5 混合扩张卷积和残差金字塔特征提取模块对性能的影响 (HAB: 混合扩张卷积模块; RPB: 残差金字塔特征提取模块)

Table 5 The influence of HAB and RPB on performance (HAB: hybrid atrous convolution block; RPB: residual pyramid feature block)

HAB	RPB	MIoU (%)
×	×	66.57
√	×	66.22
×	√	67.51
√	√	68.26

下载: 导出CSV

表 6 混合扩张卷积模块对性能的影响 (HAB: 混合扩张卷积模块; RPB: 残差金字塔特征提取模块)

Table 6 The influence of HAB on performance (HAB: hybrid atrous convolution block; RPB: residual pyramid feature block)

HAB	RPB	HAB各分支扩张率	MIoU (%)
√	×	2, 3, 4	66.22
√	×	1	67.84
√	√	1	68.16
√	√	2, 3, 4	68.26

下载: 导出CSV

表 7 混合扩张卷积模块与残差金字塔特征提取模块的结构顺序对性能的影响 (HAB: 混合扩张卷积模块; RPB: 残差金字塔特征提取模块)

Table 7 The influence of the structural order of HAB and RPB on performance (HAB: hybrid atrous convolution block; RPB: residual pyramid feature block)

方法	MIoU (%)
HAB+HAB	67.29
RPB+RPB	66.95
RPB+HAB	68.29
本文 (HAB+RPB)	68.26

下载: 导出CSV

表 8 不同空间路径对性能的影响 (CRB: 链式反置残差模块; SP: 空间路径; LFP: 浅层特征作为空间路径; HFP: 高层特征作为空间路径; RUP: 反U型空间路径)

Table 8 The influence of different spatial paths on performance (CRB: chain inverted residual block; SP: spatial path; LFP: low-level feature as spatial path; HFP: high-level feature as spatial path; RUP: reverse u-shaped spatial path)

方法	MIoU (%)
No SP	63.51
LFP	66.06
HFP	67.49
RUP	66.79
RUP+CRB	68.26

下载: 导出CSV

表 9 链式反置残差模块不同链长对性能的影响

Table 9 The influence of CRB chain length on performance

方法	MIoU (%)
各路径链长均为 1	67.20
各路径链长均为 3	67.25
本文 (分别为 3, 2, 1)	68.26

下载: 导出CSV

表 10 残差循环卷积模块对性能的影响

Table 10 The influence of RRB on performance

方法	MIoU (%)
使用优化模块	68.26
不使用优化模块	67.50

下载: 导出CSV
