基于固定时间模型参考方法的倾转旋翼无人机姿态控制

朱纪洪; 张骁骏; 杨赟杰; 袁夏明

doi:10.16383/j.aas.c240621

基于固定时间模型参考方法的倾转旋翼无人机姿态控制

doi: 10.16383/j.aas.c240621 cstr: 32138.14.j.aas.c240621

朱纪洪^{1, 3,},
张骁骏^2,,
杨赟杰^{1, 3,},
袁夏明^{1, 3,}

1.
清华大学精密仪器系北京 100084
2.
中航工业成都飞机设计研究所成都 610091
3.
时空信息精密感知技术全国重点实验室北京 100084

基金项目: 国家自然科学基金(62203259, 62073185), 航空工业成都飞机设计研究所预研项目, 航空科学基金(20240058058001)资助

详细信息

作者简介:
朱纪洪：清华大学精密仪器系、时空信息精密感知技术全国重点实验室教授. 主要研究方向为先进飞行器动力学与智能控制技术. E-mail: jhzhu@tsinghua.edu.cn

张骁骏：中航工业成都飞机设计研究所工程师. 主要研究方向为飞行器设计及飞行控制技术. E-mail: xj-zhang31@foxmail.com

杨赟杰：清华大学精密仪器系、时空信息精密感知技术全国重点实验室助理研究员. 主要研究方向为飞行动力学与非线性控制技术. 本文通信作者. E-mail: yangyunjie@tsinghua.edu.cn

袁夏明：清华大学精密仪器系、时空信息精密感知技术全国重点实验室助理研究员. 主要研究方向为无人系统及智能控制技术. E-mail: xmyuan@tsinghua.edu.cn

计量
- 文章访问数: 43
- HTML全文浏览量: 21
- 被引次数: 0
出版历程
- 录用日期: 2025-01-17
- 网络出版日期: 2025-02-26

Attitude Control of Tilt-rotor Unmanned Aerial Vehicle Based on Fixed Time Model Reference Method

ZHU Ji-Hong^{1, 3
,},
ZHANG Xiao-Jun^2
,,
YANG Yun-Jie^{1, 3
,},
YUAN Xia-Ming^{1, 3
,}

1.
Department of Precision Instrument, Tsinghua University, Beijing 100084
2.
AVIC Chengdu Aircraft Design and Research Institute, Chengdu 610091
3.
State Key Laboratory of Precision Space-time Information Sensing Technology, Beijing 100084

Funds: Supported by National Natural Science Foundation of China (62203259 and 62073185), Pre Research Project of AVIC Chengdu Aircraft Design and Research Institute, Aeronautical Science Foundation of China (20240058058001)

More Information

Author Bio:
ZHU Ji-Hong　Professor at the Department of Precision Instrument, Tsinghua University, and the State Key Laboratory of Precision Space-time Information Sensing Technology. His research interest covers advanced aircraft dynamics and intelligent control

ZHANG Xiao-Jun　Engineer at AVIC Chengdu Aircraft Design and Research Institute. His research interest covers aircraft design and flight control technology

YANG Yun-Jie　Assistant Researcher at the Department of Precision Instrument, Tsinghua University, and the State Key Laboratory of Precision Space-time Information Sensing Technology. His research interest covers flight dynamics and nonlinear control technology. Corresponding author of this paper

YUAN Xia-Ming　Assistant Researcher at the Department of Precision Instrument, Tsinghua University, and the State Key Laboratory of Precision Space-time Information Sensing Technology. His research interest covers unmanned system and intelligent control technology

摘要

摘要: 倾转旋翼无人机动力学特性复杂, 过渡过程中的变速变构型特性导致系统具有较大的模型不确定性, 且容易受到阵风扰动等的影响, 对姿态控制律设计提出了很高要求. 针对该问题, 本文建立了一种扰动观测器结合终端滑模补偿控制器的模型参考姿态控制方法. 基于齐次系统理论设计了固定时间收敛扰动观测器, 实现对倾转旋翼无人机未建模动态和外部扰动的准确估计; 基于一种新型非线性饱和函数设计了固定时间收敛终端滑模控制器, 结合低通滤波实现对指令的快速高品质跟踪; 为进一步解决控制奇异性问题, 提出了在纵轴附近邻域时对控制器的改进策略. 仿真结果表明, 所提方法在应对倾转旋翼无人机模型不确定性和外部扰动方面具有较强的鲁棒性, 相比基于有限时间稳定性理论的模型参考姿态控制方法, 固定时间收敛控制提供了更高的控制精度和更平滑的输出.
- 倾转旋翼无人机 /
- 姿态控制 /
- 固定时间收敛 /
- 模型参考控制 /
- 滑模控制
Abstract: Tilt-rotor unmanned aerial vehicles (UAVs) exhibit complex dynamic characteristics during the transition process. Their variable speed and variable configuration features result in significant model uncertainties. Meanwhile, they are easily affected by disturbances such as gusts of wind, which imposes high demands on the design of attitude control laws. To address this issue, this paper proposes a model reference attitude control method that combines a disturbance observer with a terminal sliding mode compensator. A fixed-time convergent disturbance observer is designed to accurately estimate the unmodeled dynamics and external disturbances of the tilt-rotor UAV based on homogeneous system theory. A fixed-time convergent terminal sliding mode controller is designed using a novel nonlinear saturation function, achieving fast and high-quality tracking of the reference signal with low-pass filtering. To further address the singularity issue, an improvement strategy is proposed for the controller in the vicinity of the longitudinal axis. Simulation results show that the proposed method exhibits strong robustness against model uncertainties and external disturbances for tilt-rotor UAVs. Compared to the model reference attitude control method based on finite-time stability theory, the fixed-time convergence control provides higher control accuracy and smoother output.
- Tilt-rotor UAV /
- attitude control /
- fixed-time convergent /
- model reference control /
- sliding mode control

HTML全文

图 1 倾转旋翼无人机全包线典型飞行状态

Fig. 1 Typical flight conditions of tiltrotor unmanned aerial vehicles throughout the entire flight envelope

下载: 全尺寸图片幻灯片

图 2 倾转旋翼无人机布局

Fig. 2 Tiltrotor unmanned aerial vehicle configuration

下载: 全尺寸图片幻灯片

图 3 模型参考姿态控制器架构

Fig. 3 Model reference attitude controller architecture

下载: 全尺寸图片幻灯片

图 4 闭环系统相平面图

Fig. 4 Closed-loop system phase diagram

下载: 全尺寸图片幻灯片

图 5 仿真中加入的风扰动情况

Fig. 5 Wind disturbance added to the simulation

下载: 全尺寸图片幻灯片

图 6 有限时间模型参考控制垂转平仿真结果

Fig. 6 Finite-time model reference control vertical leveling simulation results

下载: 全尺寸图片幻灯片

图 7 有限时间模型参考控制平转垂仿真结果

Fig. 7 Finite-time model reference control flat sag simulation results

下载: 全尺寸图片幻灯片

图 8 固定时间模型参考控制垂转平仿真结果

Fig. 8 Fixed time model reference control vertical leveling simulation results

下载: 全尺寸图片幻灯片

图 9 固定时间模型参考控制平转垂仿真结果

Fig. 9 The fixed time model refers to the simulation results of the horizontal sag control

下载: 全尺寸图片幻灯片

表 1 参考模型参数

Table 1 Reference model parameter

通道	$ a_{m1} $	$ a_{m2} $
滚转	$ {\left( {1 + V_x^b/15} \right)^2} $	$ 1.8 + 0.12V_x^b $
俯仰	$ \left( {2 + V_x^b/10} \right)^2 $	$ 3.2 + 0.16V_x^b $
偏航	$ {\left( {1 + V_x^b/60} \right)^2} $	$ 2.0 + V_x^b/30 $

下载: 导出CSV

表 2 有限时间模型参考控制器参数

Table 2 The finite time model refers to the controller parameters

通道	$ p $	$ \alpha $	$ p_s $	$ \alpha_s $	$ D_o $	$ \alpha_o $	$ k_1 $	$ k_2 $
滚转	0.6	1.2	1	5/9	0.8	0.95	20	100
俯仰	0.8	1.2	1	1/3	3	0.95	20	100
偏航	0.3	1.2	1	5/9	0.8	0.95	20	100

下载: 导出CSV

表 3 固定时间模型参考控制器参数

Table 3 The fixed time model refers to the controller parameters

通道	$ p $	$ \mu $	$ c $	$ p_s $	$ \mu_s $	$ c_s $	$ D_o $	$ \alpha_o $	$ k_1 $	$ k_2 $	$ \beta_o $	$ l_1 $	$ l_2 $
滚转	0.5	2/9	1	1	3/9	2	0.5	0.94	20	100	1.06	20	100
俯仰	1	2/9	2	1.5	4/9	2	2	0.94	20	100	1.06	30	225
偏航	0.5	2/9	1	1	3/9	2	0.5	0.94	20	100	1.06	20	100

下载: 导出CSV

表 4 有限/固定时间模型参考控制方法性能指标对比

Table 4 Comparison of performance indexes of fixed time model reference control methods

设计方法	$ T_E^z $	$ T_E^{\phi} $	$ T_E^{\theta} $	$ T_E^{\psi} $	$ T_E^{o\phi} $	$ T_E^{o\theta} $	$ T_E^{o\psi} $	$ T_V^{\phi} $	$ T_V^{\theta} $	$ T_V^{\psi} $
有限时间	26.57	0.06	0.55	0.08	0.44	11.42	0.56	125.73	598.62	147.77
固定时间	23.73	0.05	0.38	0.06	0.41	9.65	0.56	87.76	520.64	120.94

下载: 导出CSV

参考文献(36)

[1]	Misra A, Jayachandran S, Kenche S, Katoch A, Suresh A, Gundabattini E, et al. A review on vertical take-off and landing (VTOL) tilt-rotor and tilt wing unmanned aerial vehicles (UAVs). Journal of Engineering, 2022, 2022(1): Article No. 1803638 Misra A, Jayachandran S, Kenche S, Katoch A, Suresh A, Gundabattini E, et al. A review on vertical take-off and landing (VTOL) tilt-rotor and tilt wing unmanned aerial vehicles (UAVs). Journal of Engineering, 2022, 2022(1): Article No. 1803638
[2]	Hegde N T, George V I, Nayak C G, Kumar K. Design, dynamic modelling and control of tilt-rotor UAVs: A review. International Journal of Intelligent Unmanned Systems, 2019, 8(3): 143−161 Hegde N T, George V I, Nayak C G, Kumar K. Design, dynamic modelling and control of tilt-rotor UAVs: A review. International Journal of Intelligent Unmanned Systems, 2019, 8(3): 143−161
[3]	Eskandarpour A, Mehrandezh M, Gupta K, Ramirez-Serrano A, Soltanshah M. A constrained robust switching MPC structure for tilt-rotor UAV trajectory tracking problem. Nonlinear Dynamics, 2023, 111(18): 17247−17275 Eskandarpour A, Mehrandezh M, Gupta K, Ramirez-Serrano A, Soltanshah M. A constrained robust switching MPC structure for tilt-rotor UAV trajectory tracking problem. Nonlinear Dynamics, 2023, 111(18): 17247−17275
[4]	Govdeli Y, Bin Muzaffar S M, Raj R, Elhadidi B, Kayacan E. Unsteady aerodynamic modeling and control of pusher and tilt-rotor quadplane configurations. Aerospace Science and Technology, 2019, 94: Article No. 105421 Govdeli Y, Bin Muzaffar S M, Raj R, Elhadidi B, Kayacan E. Unsteady aerodynamic modeling and control of pusher and tilt-rotor quadplane configurations. Aerospace Science and Technology, 2019, 94: Article No. 105421
[5]	Wang Z G, Wang Q N, Yu H R, Duan D Y, Ding Z W, Li J B. Trimming analysis method of quad tilt rotor based on aerodynamic interference model. Journal of Aircraft, 2021, 58(2): 253−265 Wang Z G, Wang Q N, Yu H R, Duan D Y, Ding Z W, Li J B. Trimming analysis method of quad tilt rotor based on aerodynamic interference model. Journal of Aircraft, 2021, 58(2): 253−265
[6]	Li W, Shi S, Chen M, Wu Q X. Adaptive tracking control for the conversion mode of tilt-rotor aircraft with switched fuzzy modeling. International Journal of Fuzzy Systems, 2024, 26(4): 1203−1214 Li W, Shi S, Chen M, Wu Q X. Adaptive tracking control for the conversion mode of tilt-rotor aircraft with switched fuzzy modeling. International Journal of Fuzzy Systems, 2024, 26(4): 1203−1214
[7]	Comer A M, Chakraborty I. Full envelope flight control system design and optimization for a tilt-wing aircraft. Journal of the American Helicopter Society, 2024, 69(3): 1−18 Comer A M, Chakraborty I. Full envelope flight control system design and optimization for a tilt-wing aircraft. Journal of the American Helicopter Society, 2024, 69(3): 1−18
[8]	Bauersfeld L, Spannagl L, Ducard G J J, Onder C H. MPC flight control for a tilt-rotor VTOL aircraft. IEEE Transactions on Aerospace and Electronic Systems, 2021, 57(4): 2395−2409 Bauersfeld L, Spannagl L, Ducard G J J, Onder C H. MPC flight control for a tilt-rotor VTOL aircraft. IEEE Transactions on Aerospace and Electronic Systems, 2021, 57(4): 2395−2409
[9]	朱斌, 陈庆伟. 垂直/短距起降飞机的轨迹跟踪控制器设计. 自动化学报, 2019, 45(6): 1166−1176
[10]	Lv Z Y, Zhao Q, Sun X M, Wu Y H. Finite-time control design for a coaxial tilt-rotor UAV. IEEE Transactions on Industrial Electronics, 2024, 71(12): 16132−16142 Lv Z Y, Zhao Q, Sun X M, Wu Y H. Finite-time control design for a coaxial tilt-rotor UAV. IEEE Transactions on Industrial Electronics, 2024, 71(12): 16132−16142
[11]	Panza S, Lovera M, Sato M, Muraoka K. Structured μ-synthesis of robust attitude control laws for quad-tilt-wing unmanned aerial vehicle. Journal of Guidance, Control, and Dynamics, 2020, 43(12): 2258−2274 Panza S, Lovera M, Sato M, Muraoka K. Structured μ-synthesis of robust attitude control laws for quad-tilt-wing unmanned aerial vehicle. Journal of Guidance, Control, and Dynamics, 2020, 43(12): 2258−2274
[12]	Yu Z L, Zhang J J, Wang X Y. Thrust vectoring control of a novel tilt-rotor UAV based on backstepping sliding model method. Sensors, 2023, 23(2): Article No. 574 Yu Z L, Zhang J J, Wang X Y. Thrust vectoring control of a novel tilt-rotor UAV based on backstepping sliding model method. Sensors, 2023, 23(2): Article No. 574
[13]	刘双喜, 林泽淮, 刘伟, 闫斌斌, 黄伟. 基于INDI的倾转旋翼无人机过渡模式控制方案. 航空学报, 2024, 45(17): 236−250
[14]	Zhong J Y, Wang C, Zhang H. Transition control of a tail-sitter unmanned aerial vehicle with L1 neural network adaptive control. Chinese Journal of Aeronautics, 2023, 36(7): 460−475 Zhong J Y, Wang C, Zhang H. Transition control of a tail-sitter unmanned aerial vehicle with L1 neural network adaptive control. Chinese Journal of Aeronautics, 2023, 36(7): 460−475
[15]	Zhang D, Wei B. A review on model reference adaptive control of robotic manipulators. Annual Reviews in Control, 2017, 43: 188−198 Zhang D, Wei B. A review on model reference adaptive control of robotic manipulators. Annual Reviews in Control, 2017, 43: 188−198
[16]	Hou Z S, Xiong S S. On model-free adaptive control and its stability analysis. IEEE Transactions on Automatic Control, 2019, 64(11): 4555−4569 Hou Z S, Xiong S S. On model-free adaptive control and its stability analysis. IEEE Transactions on Automatic Control, 2019, 64(11): 4555−4569
[17]	Anderson R B, Marshall J A, L'Afflitto A. Constrained robust model reference adaptive control of a tilt-rotor quadcopter pulling an unmodeled cart. IEEE Transactions on Aerospace and Electronic Systems, 2021, 57(1): 39−54 Anderson R B, Marshall J A, L'Afflitto A. Constrained robust model reference adaptive control of a tilt-rotor quadcopter pulling an unmodeled cart. IEEE Transactions on Aerospace and Electronic Systems, 2021, 57(1): 39−54
[18]	Liu N J, Cai Z H, Zhao J, Wang Y X. Predictor-based model reference adaptive roll and yaw control of a quad-tiltrotor UAV. Chinese Journal of Aeronautics, 2020, 33(1): 282−295 Liu N J, Cai Z H, Zhao J, Wang Y X. Predictor-based model reference adaptive roll and yaw control of a quad-tiltrotor UAV. Chinese Journal of Aeronautics, 2020, 33(1): 282−295
[19]	Liu Y, Li H Y, Lu R Q, Zuo Z Y, Li X D. An overview of finite/fixed-time control and its application in engineering systems. IEEE/CAA Journal of Automatica Sinica, 2022, 9(12): 2106−2120 Liu Y, Li H Y, Lu R Q, Zuo Z Y, Li X D. An overview of finite/fixed-time control and its application in engineering systems. IEEE/CAA Journal of Automatica Sinica, 2022, 9(12): 2106−2120
[20]	Sun Z Y, Shao Y, Chen C C. Fast finite-time stability and its application in adaptive control of high-order nonlinear system. Automatica, 2019, 106: 339−348 Sun Z Y, Shao Y, Chen C C. Fast finite-time stability and its application in adaptive control of high-order nonlinear system. Automatica, 2019, 106: 339−348
[21]	Song Y D, Ye H F, Lewis F L. Prescribed-time control and its latest developments. IEEE Transactions on Systems, Man, and Cybernetics: Systems, 2023, 53(7): 4102−4116 Song Y D, Ye H F, Lewis F L. Prescribed-time control and its latest developments. IEEE Transactions on Systems, Man, and Cybernetics: Systems, 2023, 53(7): 4102−4116
[22]	Bhat S P, Bernstein D S. Lyapunov analysis of finite-time differential equations. In: Proceedings of the American Control Conference (ACC). Seattle, USA: IEEE, 1995. 1831−1832 Bhat S P, Bernstein D S. Lyapunov analysis of finite-time differential equations. In: Proceedings of the American Control Conference (ACC). Seattle, USA: IEEE, 1995. 1831−1832
[23]	Bhat S P, Bernstein D S. Finite-time stability of homogeneous systems. In: Proceedings of the American Control Conference (ACC). Albuquerque, USA: IEEE, 1997. 2513−2514 Bhat S P, Bernstein D S. Finite-time stability of homogeneous systems. In: Proceedings of the American Control Conference (ACC). Albuquerque, USA: IEEE, 1997. 2513−2514
[24]	Polyakov A, Fridman L. Stability notions and Lyapunov functions for sliding mode control systems. Journal of the Franklin Institute, 2014, 351(4): 1831−1865 Polyakov A, Fridman L. Stability notions and Lyapunov functions for sliding mode control systems. Journal of the Franklin Institute, 2014, 351(4): 1831−1865
[25]	Andrieu V, Praly L, Astolfi A. Homogeneous approximation, recursive observer design, and output feedback. SIAM Journal on Control and Optimization, 2008, 47(4): 1814−1850 Andrieu V, Praly L, Astolfi A. Homogeneous approximation, recursive observer design, and output feedback. SIAM Journal on Control and Optimization, 2008, 47(4): 1814−1850
[26]	Ding S H, Mei K Q, Yu X H. Adaptive second-order sliding mode control: A Lyapunov approach. IEEE Transactions on Automatic Control, 2022, 67(10): 5392−5399 Ding S H, Mei K Q, Yu X H. Adaptive second-order sliding mode control: A Lyapunov approach. IEEE Transactions on Automatic Control, 2022, 67(10): 5392−5399
[27]	Abdul Ghaffar A F, Richardson T, Greatwood C. A combined model reference adaptive control law for multirotor UAVs. IET Control Theory & Applications, 2021, 15(11): 1474−1487 Abdul Ghaffar A F, Richardson T, Greatwood C. A combined model reference adaptive control law for multirotor UAVs. IET Control Theory & Applications, 2021, 15(11): 1474−1487
[28]	Marshall J A, Carter G I, L'Afflitto A. Model reference adaptive control for prescribed performance and longitudinal control of a tail-sitter UAV. In: Proceedings of AIAA SCITECH 2022 Forum. San Diego, USA: AIAA, 2022. 1380 Marshall J A, Carter G I, L'Afflitto A. Model reference adaptive control for prescribed performance and longitudinal control of a tail-sitter UAV. In: Proceedings of AIAA SCITECH 2022 Forum. San Diego, USA: AIAA, 2022. 1380
[29]	Sun H B, Hou L L, Zong G D, Yu X H. Fixed-time attitude tracking control for spacecraft with input quantization. IEEE Transactions on Aerospace and Electronic Systems, 2019, 55(1): 124−134 Sun H B, Hou L L, Zong G D, Yu X H. Fixed-time attitude tracking control for spacecraft with input quantization. IEEE Transactions on Aerospace and Electronic Systems, 2019, 55(1): 124−134
[30]	Wang J H, Alattas K A, Bouteraa Y, Mofid O, Mobayen S. Adaptive finite-time backstepping control tracker for quadrotor UAV with model uncertainty and external disturbance. Aerospace Science and Technology, 2023, 133: Article No. 108088 Wang J H, Alattas K A, Bouteraa Y, Mofid O, Mobayen S. Adaptive finite-time backstepping control tracker for quadrotor UAV with model uncertainty and external disturbance. Aerospace Science and Technology, 2023, 133: Article No. 108088
[31]	Xiao J, Zeng Z G, Wen S P, Wu A L, Wang L M. A unified framework design for finite-time and fixed-time synchronization of discontinuous neural networks. IEEE Transactions on Cybernetics, 2021, 51(6): 3004−3016 Xiao J, Zeng Z G, Wen S P, Wu A L, Wang L M. A unified framework design for finite-time and fixed-time synchronization of discontinuous neural networks. IEEE Transactions on Cybernetics, 2021, 51(6): 3004−3016
[32]	Wang C Y, Dong W, Wang J N, Shan J Y, Xin M. Guidance law design with fixed-time convergent error dynamics. Journal of Guidance, Control, and Dynamics, 2021, 44(7): 1389−1398 Wang C Y, Dong W, Wang J N, Shan J Y, Xin M. Guidance law design with fixed-time convergent error dynamics. Journal of Guidance, Control, and Dynamics, 2021, 44(7): 1389−1398
[33]	Cheng W L, Zhang K, Jiang B. Fixed-time and prescribed-time fault-tolerant optimal tracking control for heterogeneous multiagent systems. IEEE Transactions on Automation Science and Engineering, 2024, 21(4): 7275−7286 Cheng W L, Zhang K, Jiang B. Fixed-time and prescribed-time fault-tolerant optimal tracking control for heterogeneous multiagent systems. IEEE Transactions on Automation Science and Engineering, 2024, 21(4): 7275−7286
[34]	Zhu J H, Yang Y J, Wang X Y, Yuan X M, Yang X. Attitude control of a novel tilt-wing UAV in hovering flight. Science China Information Sciences, 2023, 66(5): Article No. 154201 Zhu J H, Yang Y J, Wang X Y, Yuan X M, Yang X. Attitude control of a novel tilt-wing UAV in hovering flight. Science China Information Sciences, 2023, 66(5): Article No. 154201
[35]	Basin M, Yu P, Shtessel Y. Finite- and fixed-time differentiators utilising HOSM techniques. IET Control Theory & Applications, 2017, 11(8): 1144−1152 Basin M, Yu P, Shtessel Y. Finite- and fixed-time differentiators utilising HOSM techniques. IET Control Theory & Applications, 2017, 11(8): 1144−1152
[36]	Venkataraman S T, Gulati S. Control of nonlinear systems using terminal sliding modes. Journal of Dynamic Systems, Measurement, and Control, 1993, 115(3): 554−560 Venkataraman S T, Gulati S. Control of nonlinear systems using terminal sliding modes. Journal of Dynamic Systems, Measurement, and Control, 1993, 115(3): 554−560
