卷积神经网络表征可视化研究综述

司念文 张文林 屈丹 罗向阳 常禾雨 牛铜

司念文, 张文林, 屈丹, 罗向阳, 常禾雨, 牛铜. 卷积神经网络表征可视化研究综述. 自动化学报, 2021, x(x): 1−31 doi: 10.16383/j.aas.c200554
引用本文: 司念文, 张文林, 屈丹, 罗向阳, 常禾雨, 牛铜. 卷积神经网络表征可视化研究综述. 自动化学报, 2021, x(x): 1−31 doi: 10.16383/j.aas.c200554
Si Nian-Wen, Zhang Wen-Lin, Qu Dan, Luo Xiang-Yang, Chang He-Yu, Niu Tong. Representation visualization of convolutional neural networks: a research survey. Acta Automatica Sinica, 2021, x(x): 1−31 doi: 10.16383/j.aas.c200554
Citation: Si Nian-Wen, Zhang Wen-Lin, Qu Dan, Luo Xiang-Yang, Chang He-Yu, Niu Tong. Representation visualization of convolutional neural networks: a research survey. Acta Automatica Sinica, 2021, x(x): 1−31 doi: 10.16383/j.aas.c200554

卷积神经网络表征可视化研究综述

doi: 10.16383/j.aas.c200554
基金项目: 国家自然科学基金(61673395, U1804263), 中原科技创新领军人才项目(214200510019)资助
详细信息
    作者简介:

    司念文:信息工程大学信息系统工程学院博士研究生, 主要研究方向为深度学习的安全性与可解释性. E-mail: snw1608@163.com

    张文林:信息工程大学信息系统工程学院副教授, 主要研究方向为深度学习和语音识别. 本文通信作者. E-mail: zwlin_2004@163.com

    屈丹:信息工程大学信息系统工程学院教授, 主要研究方向为机器学习、深度学习和语音识别. 本文通信作者. E-mail: qudanqudan@163.com

    罗向阳:信息工程大学网络空间安全学院教授, 主要研究方向为人工智能与信息安全. E-mail: xiangyangluo@126.com

    常禾雨:信息工程大学密码工程学院博士研究生, 主要研究方向为深度学习与行人重识别. E-mail: okaychy@163.com

    牛铜:信息工程大学信息系统工程学院副教授, 主要研究方向为深度学习和语音识别. E-mail: jerry_newton@sina.com

Representation Visualization of Convolutional Neural Networks: A Research Survey

Funds: Supported by National Natural Science Foundation of P. R. China (61673395, U1804263), Zhongyuan Science and Technology Innovation Leading Talent Project (214200510019)
More Information
    Author Bio:

    SI Nian-Wen Ph.D. candidate in the College of Information System Engingeering, Information Engineering University. His research interest covers deep learning security and interpretability

    ZHANG Wen-Lin Associate professor in the College of Information System Engingeering, Information Engineering University. His research interest covers deep learning and speech recognition. Corresponding author of this paper

    QU Dan Professor in the College of Information System Engingeering, Information Engineering University. Her research interests cover machine learning, deep learning, and speech recognition. Corresponding author of this paper

    LUO Xiang-Yang Professor in the College of Cyberspace Security, Information Engineering University. His research interest covers artificial intelligence and information security

    CHANG He-Yu Ph.D. candidate in the College of Cryptographic Engineering, Information Engineering University. Her research interest covers deep learning and person re-identification

    NIU Tong Associate professor in the College of Information System Engingeering, Information Engineering University. His research interest covers deep learning and speech recognition

  • 摘要: 近年来, 深度学习在图像分类、目标检测及场景识别等任务上取得了突破性进展, 这些任务多以卷积神经网络(Convolutional neural network, CNN)为基础搭建识别模型, 训练后的模型拥有优异的自动特征提取和预测性能, 能够为用户提供“输入-输出”形式的解决方案. 然而, 由于分布式的特征编码和越来越复杂的模型结构, 人们始终无法准确理解CNN模型内部知识表示, 以及促使其做出特定决策的潜在原因. 另一方面, CNN模型在一些高风险领域的应用, 也要求对其决策原因进行充分了解, 方能获取用户信任. 因此, CNN的可解释性问题逐渐受到关注. 研究人员针对性的提出了一系列用于理解和解释CNN的方法, 包括事后解释方法和构建自解释的模型等, 这些方法各有侧重和优势, 从多方面对CNN进行特征分析和决策解释. 表征可视化是其中一种重要的CNN可解释性方法, 能够对CNN所学特征及输入-输出之间的相关关系以视觉的方式呈现, 从而快速获取对CNN内部特征和决策的理解, 具有过程简单和效果直观的特点. 本文对近年来CNN表征可视化领域的相关文献进行了综合性回顾, 按照以下几个方面组织内容: 表征可视化研究的提起、相关概念及内容、可视化方法、可视化的效果评估及可视化的应用, 重点关注了表征可视化方法的分类及算法的具体过程. 最后, 对该领域仍存在的难点及未来研究趋势进行了展望, 并总结了全文.
  • 图  1  传统机器学习与深度学习的学习过程对比[8]

    Fig.  1  Comparison of the learning process between traditional machine learning and deep learning[8]

    图  2  可解释性深度学习的研究内容划分

    Fig.  2  The division of the research content of the interpretable deep learning

    图  3  CNN表征可视化的研究思路

    Fig.  3  The research idea of CNN representation visualization

    图  4  CNN表征可视化的研究内容

    Fig.  4  Research content of the CNN representation visualization

    图  5  基于扰动的方法的解释流程

    Fig.  5  Interpretation process of the perturbation based method

    图  6  使用随机采样产生扰动掩码的过程[43].

    Fig.  6  The process of generating a perturbation mask using random sampling[43].

    图  7  使用生成式模型生成扰动[45]

    Fig.  7  Using generative models to generate perturbation[45]

    图  8  基于反向传播的方法的解释流程

    Fig.  8  Interpretation process backpropagation based method

    图  9  VBP方法的过程[49]

    Fig.  9  The process of the VBP method[49]

    图  10  梯度不稳定导致解释结果的不确定性[51]

    Fig.  10  Uncertainty of interpretation results due to gradient instability[51]

    图  11  梯度方法产生的显著图含有大量噪声[44]

    Fig.  11  The saliency map generated by the gradient method contains a lot of noise[44]

    图  12  单个像素的梯度值的不稳定性[52]

    Fig.  12  The instability of the gradient value of a single pixel[52]

    图  13  反卷积可视化方法的过程

    Fig.  13  The process of deconvolution visualization method

    图  14  VBP、GBP和反卷积三者之间的关系[49].

    Fig.  14  The relationship of VBP, GBP and deconvolution [49].

    图  15  LRP的过程

    Fig.  15  The process of the LRP

    图  16  LRP正向传播的过程[19]

    Fig.  16  The forward propagation process of the LRP[19]

    图  17  LRP反向传播的过程[19]

    Fig.  17  The backpropagation process of the LRP[19]

    图  18  CAM的过程

    Fig.  18  The process of the CAM

    图  19  Grad-CAM的过程

    Fig.  19  The process of the Grad-CAM

    图  20  Score-CAM的过程[66]

    Fig.  20  The process of the Score-CAM[66]

    图  21  AM的过程

    Fig.  21  The process of the AM

    图  22  DGN-AM的过程

    Fig.  22  The process of the DGN-AM

    图  23  在MNIST数据集上使用AM方法对目标CNN模型的可视化结果对比[19]

    Fig.  23  Comparison of the visualization results of the target CNN model using the AM method on the MNIST dataset[19]

    图  24  Squeeze-and-Excitation模块[18]

    Fig.  24  Squeeze-and-Excitation module[18]

    图  25  通道-空间注意力模块[72]

    Fig.  25  Channel-spatial attention module[72]

    图  26  通道注意力模块[72]

    Fig.  26  Channel attention module[72]

    图  27  空间注意力模块[72]

    Fig.  27  Spatial attention module[72]

    图  28  ResNet50、集成SENet的ResNet50 (ResNet50 + SE)和集成CBAM的ResNet50 (ResNet50 +CBAM)的最高层特征图的可视化[72].

    Fig.  28  Visualization of the highest-level feature maps of ResNet50, ResNet50 integrated with SEnet (ResNet50 + SE), and ResNet50 integrated with CBAM (ResNet50 + CBAM)[72].

    图  29  LIME的样本处理流程

    Fig.  29  the sample processing flow of the LIME

    图  30  LIME在AlexNet、VGGNet16及ResNet50模型上可视化结果示例.

    Fig.  30  Example of LIME visualization results on AlexNet, VGGNet16 and ResNet50 models.

    图  31  热力图的后处理与效果对比

    Fig.  31  Post-processing and effect comparison of heatmap

    图  32  可视化方法的效果比较. 每张输入图像分别展示了灰度和彩色两种可视化结果.

    Fig.  32  Comparison of the effects of visualization methods. Each input image shows two visualization results of grayscale and color image.

    图  33  FGSM生成对抗样本的过程[87]

    Fig.  33  The process of generating adversarial examples by FGSM[87]

    图  34  使用FGSM对抗样本测试Grad-CAM的稳定性[63]

    Fig.  34  Using FGSM adversarial samples to test the stability of Grad-CAM[63]

    图  35  针对可视化结果的攻击.

    Fig.  35  Attacks on the visualization results.

    图  36  使用GAN生成的目标图像诱导对LRP显著图的攻击[83][90]

    Fig.  36  Using the target image generated by GAN to induce an attack on the LRP saliency map[83][90]

    表  1  梯度方法及其变种的特点比较

    Table  1  Comparison of the characteristics of the gradient method and its variants

    方法显著图生成依据特点
    VBP普通梯度过程简单, 但存在梯度噪声问题.
    GBP每一层使用ReLU过程简单, 但存在梯度噪声问题.
    积分梯度梯度图的平均过程复杂, 需多次迭代, 耗时.
    平滑梯度梯度图的平均过程复杂, 需多次迭代, 耗时.
    整流梯度阈值过滤后的梯度过程较复杂, 阈值的选取需要经验.
    下载: 导出CSV

    表  2  类激活映射方法的比较

    Table  2  Comparision of the class activation mapping methods

    方法通道权重优点缺点
    CAMsoftmax层权重类别区分性依赖GAP层
    Grad-CAM各通道的梯度平均值类别区分性, 结构通用梯度不稳定
    Grad-CAM++各通道的梯度平均值, 高阶梯度类别区分性, 结构通用梯度不稳定, 高阶梯度计算复杂
    Score-CAM对各通道的预测值类别区分性, 结构通用, 权重稳定权重计算过程复杂, 重复迭代耗时.
    下载: 导出CSV

    表  3  可视化方法的特点比较

    Table  3  Comparison of characteristics of visualization methods

    方法分类方法发表时间细粒度/
    区域级
    是否类别相关在线/
    离线
    模型明晰的/
    模型不可知的
    可视化视角局部解释/
    全局解释
    扰动简单扰动[13][42][43]2014, 2018区域级离线模型不可知的输出类局部
    有意义的扰动[44]2017区域级离线模型明晰的输出类局部
    生成式扰动[45][46]2019区域级离线模型明晰的输出类局部
    反向传播梯度类反向传播VBP[22][23]2013, 2014细粒度离线模型明晰的输出类局部
    GBP[50]2017细粒度离线模型明晰的输出类局部
    smooth gradient[52]2017细粒度离线模型明晰的输出类局部
    integrated gradient[53]2017细粒度离线模型明晰的输出类局部
    rectified gradient[54]2019细粒度离线模型明晰的输出类局部
    规则类反向传播Deconvolution[13]2014细粒度离线模型明晰的神经元/层局部
    LRP[58]2015细粒度离线模型明晰的输出类局部
    DTD[61]2017细粒度离线模型明晰的输出类局部
    CLRP[59], SGLRP[60]2019细粒度离线模型明晰的输出类局部
    类激活映射CAM[62]2015区域级在线模型明晰的输出类局部
    Grad-CAM[63][64]2016区域级离线模型明晰的输出类局部
    Grad-CAM++[65]2018区域级离线模型明晰的输出类局部
    Score-CAM[66]2019区域级离线模型明晰的输出类局部
    激活最大化AM[82]2009细粒度离线模型明晰的神经元/输出类全局
    DGN-AM[83]2016细粒度离线模型明晰的神经元/输出类全局
    注意为掩码通道注意力[18]2017区域级在线模型明晰的局部
    空间-通道注意力[72]2018区域级在线模型明晰的局部
    类别注意力区域级在线模型明晰的
    其它方法LIME[78]2016区域级离线模型不可知的输出类局部
    SHAP[79]2017细粒度离线模型不可知的输出类局部
    下载: 导出CSV

    表  4  CNN表征可视化相关的综述文献统计

    Table  4  Review literature statistics related to CNN representation visualization

    文献发表时间内容侧重
    [114]2016几种典型的特征可视化方法(扰动、
    反向传播、激活最大化等),
    以及相互之间的关系分析
    [115]2017特征可视化的必要性, 基于反向传播的可视化方法.
    [116]2017模型可视化, 不限于CNN可解释性领域.
    [19]2018基于反向传播的可视化方法(AM, VBP, DTD, LRP等)
    [117]2018自解释的CNN
    [20]2018可解释性的概念, 相关文献分类.
    [118]2018人工智能的可解释性
    [103]2019机器学习的可解释性方法与评估
    [119]2020机器学习的可解释性
    [120]2020深度学习的可解释性
    [121]2020人工智能的可解释性
    [122]2020人工智能的可解释性
    下载: 导出CSV
