一种多运动模式的仿生软体爬行机器人设计与性能研究

刘晓华; 王耀南; 冯运

doi:10.16383/j.aas.c250680

一种多运动模式的仿生软体爬行机器人设计与性能研究

doi: 10.16383/j.aas.c250680 cstr: 32138.14.j.aas.c250680

刘晓华^{1, 2,},
王耀南^{1, 2,},
冯运^{1, 2,}

1.
湖南大学人工智能与机器人学院长沙 410082
2.
机器人视觉感知与控制技术国家工程研究中心长沙 410082

基金项目: 国家重点研发计划(2023YFB4706400), 国家自然科学基金(62522311, 62473143), 湖南省自然科学基金(2024JJ5087), 广东省自然科学基金(2025A1515011482), 工业控制技术全国重点实验室开放基金(ICT2025B03), 工业物联网与网络化控制教育部重点实验室开放基金(2024FF01), 自主智能无人系统全国重点实验室开放基金(ZZKF2025-3-3), 广东省家用电器基础技术重点实验室开放基金(GJJZ20250103), 江西省自然科学基金(20232BAB212024), 湖南省研究生科研创新项目(CX20240414)资助

详细信息

作者简介:
刘晓华：湖南大学人工智能与机器人学院博士研究生. 2023年获得湖南大学硕士学位. 主要研究方向为软体机器人设计、建模和控制. E-mail: liuxh@hnu.edu.cn

王耀南：中国工程院院士, 湖南大学人工智能与机器人学院教授. 1995年获得湖南大学博士学位. 主要研究方向为机器人学, 智能控制和图像处理. E-mail: yaonan@hnu.edu.cn

冯运：湖南大学人工智能与机器人学院副教授, 机器人视觉感知与控制技术国家工程研究中心研究员. 主要研究方向为机器人数字孪生, 软体机器人建模与控制. 本文通信作者. E-mail: fyrobot@hnu.edu.cn

计量
- 文章访问数: 125
- HTML全文浏览量: 85
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-12-01
- 网络出版日期: 2026-04-24
- 刊出日期: 2026-05-20

Design and Performance Study of a Biomimetic Soft Crawling Robot With Multiple Motion Modes

LIU Xiao-Hua^{1, 2
,},
WANG Yao-Nan^{1, 2
,},
FENG Yun^{1, 2
,}

1.
School of Artificial Intelligence and Robotics, Hunan University, Changsha 410082
2.
National Engineering Research Center of Robot Visual Perception and Control Technology, Changsha 410082

Funds: Supported by National Key Research and Development Program of China (2023YFB4706400), National Natural Science Foundation of China (62522311, 62473143), Natural Science Foundation of Hunan Province (2024JJ5087), Natural Science Foundation of Guangdong Province (2025A1515011482), Open Fund of the State Key Laboratory of Industrial Control Technology (ICT2025B03), Open Fund of the Key Laboratory of Industrial Internet of Things and Networked Control, Ministry of Education (2024FF01), Open Fund of State Key Laboratory of Autonomous Intelligent Unmanned Systems (ZZKF2025-3-3), Open Fund of Guangdong Provincial Key Laboratory of Basic Technology for Household Appliances (GJJZ20250103), Natural Science Foundation of Jiangxi Province (20232BAB212024), and Postgraduate Scientific Research Innovation Project of Hunan Province (CX20240414)

More Information

Author Bio:
LIU Xiao-Hua　Ph.D. candidate at the School of Artificial Intelligence and Robotics, Hunan University. He received his master degree from Hunan University in 2023. His research interests include soft robot design, modeling, and control

WANG Yao-Nan　Academician at Chinese Academy of Engineering, professor at the School of Artificial Intelligenceand Robotics, Hunan University. He received his Ph.D. degree from Hunan University in 1995. His research interests include robotics, intelligent control, and image processing

FENG Yun　Associate professor at the School of Artificial Intelligence and Robotics, Hunan University, researcher at the National Engineering Research Center of Robot Visual Perception and Control Technology. His research interests include robot digital twins, and soft robot modeling and control. Corresponding author of this paper

摘要

摘要: 仿生关节结构和多模式爬行机器人对复杂环境下的柔顺运动具有重要意义. 针对现有爬行机器人运动模式单一的问题, 首先设计一种受章鱼触腕肌肉结构启发的三腔气动关节. 该关节实现模块化设计和三维空间的差异化轨迹运动. 基于该关节提出并研制一种兼具多种运动模式的仿生爬行机器人. 通过选择不同的气压激励方式, 机器人在同一平台上实现类似蜥蜴的纵向爬行和类似螃蟹的横向爬行, 分别实现142.54 mm/min和90.02 mm/min的移动速度. 本文围绕关节设计原理、结构实现、制造工艺及机器人集成与运动验证进行系统研究, 为气动关节设计和多模式仿生爬行机器人的开发提供新的技术途径.
- 软体机器人 /
- 仿生设计 /
- 爬行机器人 /
- 气动关节
Abstract: Biomimetic joint structures and crawling robots with multiple motion modes play an important role in achieving compliant locomotion in complex environments. To address the limitation of single-mode locomotion in existing crawling robots, this study first designs a three-chamber pneumatic joint inspired by the muscular structure of octopus arms. The joint features a modular design and enables differential trajectory motion in three-dimensional space. Based on this joint, a biomimetic crawling robot with multiple locomotion modes has been designed and developed. By selecting different pneumatic excitation patterns, the robot can perform lizard-like longitudinal crawling and crab-like lateral crawling on the same platform, achieving locomotion speeds of 142.54 mm/min and 90.02 mm/min, respectively. The study systematically investigates the joint design principles, structural implementation, fabrication process, robot integration, and motion validation, providing a new technical pathway for the design of pneumatic joints and the development of crawling robots with multiple motion modes.
- soft robots /
- biomimetic design /
- crawling robots /
- pneumatic joints
