摘要: 群组推荐在信息检索与数据挖掘领域近年来备受关注, 其旨在从海量候选集中挑选出一组用户可能感兴趣的项目. 随着深度学习技术的不断发展, 基于深度学习的群组推荐方法大量涌现. 鉴于此, 首先介绍群组推荐问题的背景知识, 然后系统综述数据获取方法, 全面评述近年来基于深度学习的群组推荐算法, 并进行系统分类与深入分析. 此外, 还归纳了适用于深度学习方法的群组推荐数据集和评价方法, 对各类推荐算法进行对比实验分析与讨论. 最后, 针对本领域的研究难点进行深入探讨, 并提出未来有待深入研究的方向.Abstract: Group recommendation has emerged as a highly active research topic in the fields of information retrieval and data mining in recent years. Its objective is to select a group of items from a large candidate set that is likely to be of interest to a set of users. With the advancement of deep learning, numerous group recommendation methods based on deep learning have been proposed. This paper provides a brief introduction to the background knowledge of this problem. It reviews the methods of data acquisition and conducts a comprehensive review, systematic classification, and in-depth analysis of group recommendation algorithms based on deep learning. In addition, this paper outlines some group recommendation datasets and evaluation methods suitable for deep methods, and conducts comparative experimental analysis and discussion on various recommendation algorithms. Finally, the research challenges in this field were analyzed, and valuable future research directions were discussed.
-
肺癌是世界范围内发病率和死亡率最高的疾病之一, 占所有癌症病发症的18 %左右[1].美国癌症社区统计显示, 80 %到85 %的肺癌为非小细胞肺癌[2].在该亚型中, 大多数病人会发生淋巴结转移, 在手术中需对转移的淋巴结进行清扫, 现阶段通常以穿刺活检的方式确定淋巴结的转移情况.因此, 以非侵入性的方式确定淋巴结的转移情况对临床治疗具有一定的指导意义[3-5].然而, 基本的诊断方法在无创淋巴结转移的预测上存在很大挑战.
影像组学是针对医学影像的兴起的热门方法, 指通过定量医学影像来描述肿瘤的异质性, 构造大量纹理图像特征, 对临床问题进行分析决策[6-7].利用先进机器学习方法实现的影像组学已经大大提高了肿瘤良恶性的预测准确性[8].研究表明, 通过客观定量的描述影像信息, 并结合临床经验, 对肿瘤进行术前预测及预后分析, 将对临床产生更好的指导价值[9].
本文采用影像组学的方法来解决非小细胞肺癌淋巴结转移预测的问题.通过利用套索逻辑斯特回归(Lasso logistics regression, LLR)[10]模型得出基本的非小细胞肺癌淋巴结的转移预测概率, 并把组学模型的预测概率作为独立的生物标志物, 与患者的临床特征一起构建多元Logistics预测模型并绘制个性化诺模图, 在临床决策中的起重要参考作用.
1. 材料和方法
1.1 病人数据
我们收集了广东省人民医院2007年5月至2014年6月期间的717例肺癌病例.这些病人在签署知情同意书后, 自愿提供自己的信息作为研究使用.为了充分利用收集到的数据对非小细胞肺癌淋巴结转移预测, 即对$N1-N3$与$N0$进行有效区分, 我们对收集的数据设置了三个入组标准: 1)年龄大于等于18周岁, 此时的肺部已经发育完全, 消除一定的干扰因素; 2)病理诊断为非小细胞肺癌无其他疾病干扰, 并有完整的CT (Computed tomography)增强图像及个人基本信息; 3)有可利用的术前病理组织活检分级用于确定N分期.经筛选, 共564例病例符合进行肺癌淋巴结转移预测研究的要求(如图 1).
为了得到有价值的结果, 考虑到数据的分配问题, 为了保证客观性, 防止挑数据的现象出现, 在数据分配上, 训练集与测试集将按照时间进行划分, 并以2013年1月为划分点.得到训练集: 400例, 其中, 243例正样本$N1-N3$, 157例负样本$N0$; 测试集: 164例, 其中, 93例正样本, 71例负样本.
1.2 病灶分割
在进行特征提取工作前, 首先要对肿瘤病灶进行分割.医学图像分割的金标准是需要有经验的医生进行手动勾画的结果.但手动分割无法保证每次的分割结果完全一致, 且耗时耗力, 尤其是在数据量很大的情况下.因此, 手动分割不是最理想的做法.在本文中, 使用的自动图像分割算法为基于雪橇的自动区域生长分割算法[11], 该算法首先选定最大切片层的种子点, 这时一般情况下最大切片为中间层的切片, 然后估计肿瘤的大小即直径, 作为一个输入参数, 再自动进行区域生长得到每个切片的肿瘤如图 2(a1), (b1), 之后我们进行雪橇滑动到邻接的上下两个切面, 进行分割, 这样重复上述的区域生长即滑动切片, 最终分割得到多个切片的的肿瘤区域, 我们将肿瘤切面层进行组合, 得到三维肿瘤如图 2(a2), (b2).
1.3 特征的提取与筛选
利用影像组学处理方法, 从分割得到的肿瘤区域中总共提取出386个特征.这些特征可分为四组:三维形状特征, 表面纹理特征, Gabor特征和小波特征[12-13].形状特征通过肿瘤体积、表面积、体积面积比等特征描述肿瘤在空间和平面上的信息.纹理特征通过统计三维不同方向上像素的规律, 通过不同的分布规律来表示肿瘤的异质性. Gabor特征指根据特定方向, 特定尺度筛选出来的纹理信息.
小波特征是指原图像经过小波变换滤波器后的纹理特征.在模式识别范畴中, 高维特征会增加计算复杂度, 此外, 高维的特征往往存在冗余性, 容易造成模型过拟合.因此, 本位通过特征筛选方法首先对所有特征进行降维处理.
本文采用$L$1正则化Lasso进行特征筛选, 对于简单线性回归模型定义为:
$$ \begin{equation} f(x)=\sum\limits_{j=1}^p {w^jx^j} =w^\mathrm{T}x \end{equation} $$ (1) 其中, $x$表示样本, $w$表示要拟合的参数, $p$表示特征的维数.
要进行参数$w$学习, 应用二次损失来表示目标函数, 即:
$$ \begin{equation} J(w)=\frac{1}{n}\sum\limits_{i=1}^n{(y_i-f(x_i)})^2= \frac{1}{n}\vert\vert\ {{y}-Xw\vert\vert}^2 \end{equation} $$ (2) 其中, $X$是数据矩阵, $X=(x_1 , \cdots, x_n)^\mathrm{T}\in {\bf R}^{n\times p}$, ${y}$是由标签组成的列向量, ${y}=(y_1, \cdots, y_n )^\mathrm{T}$.
式(2)的解析解为:
$$ \begin{equation} \hat{w}=(X^\mathrm{T}X)^{-1}X^\mathrm{T}{y} \end{equation} $$ (3) 然而, 若$p\gg n$, 即特征维数远远大于数据个数, 矩阵$X^\mathrm{T}X$将不是满秩的, 此时无解.
通过Lasso正则化, 得到目标函数:
$$ \begin{equation} J_L(w)=\frac{1}{n} \vert\vert{y}-Xw\vert\vert^2+\lambda\vert\vert w\vert\vert _1 \end{equation} $$ (4) 目标函数最小化等价为:
$$ \begin{equation} \mathop {\min }\limits_w \frac{1}{n} \vert\vert{y}-Xw\vert\vert^2, \, \, \, \, \, \, \, \mathrm{s.t.}\, \, \vert \vert w\vert \vert _1 \le C \end{equation} $$ (5) 为了使部分特征排除, 本文采用$L$1正则方法进行压缩.二维情况下, 在$\mbox{(}w^1, w^2)$平面上可画出目标函数的等高线, 取值范围则为平面上半径为$C$的$L$1范数圆, 等高线与$L$1范数圆的交点为最优解. $L$1范数圆和每个坐标轴相交的地方都有"角''出现, 因此在角的位置将产生稀疏性.而在维数更高的情况下, 等高线与L1范数球的交点除角点之外还可能产生在很多边的轮廓线上, 同样也会产生稀疏性.对于式(5), 本位采用近似梯度下降(Proximal gradient descent)[14]算法进行参数$w$的迭代求解, 所构造的最小化函数为$Jl=\{g(w)+R(w)\}$.在每次迭代中, $Jl(w)$的近似计算方法如下:
$$ \begin{align} J_L (w^t+d)&\approx \tilde {J}_{w^t} (d)=g(w^t)+\nabla g(w^t)^\mathrm{T}d\, +\nonumber\\ &\frac{1} {2d^\mathrm{T}(\frac{I }{ \alpha })d}+R(w^t+d)=\nonumber\\ &g(w^t)+\nabla g(w^t)^\mathrm{T}d+\frac{{d^\mathrm{T}d} } {2\alpha } +\nonumber\\ &R(w^t+d) \end{align} $$ (6) 更新迭代$w^{(t+1)}\leftarrow w^t+\mathrm{argmin}_d \tilde {J}_{(w^t)} (d)$, 由于$R(w)$整体不可导, 因而利用子可导引理得:
$$ \begin{align} w^{(t+1)}&=w^t+\mathop {\mathrm{argmin}} \nabla g(w^t)d^\mathrm{T}d\, +\nonumber\\ &\frac{d^\mathrm{T}d}{2\alpha }+\lambda \vert \vert w^t+d\vert \vert _1=\nonumber\\ &\mathrm{argmin}\frac{1 }{ 2}\vert \vert u-(w^t-\alpha \nabla g(w^t))\vert \vert ^2+\nonumber\\ &\lambda \alpha \vert \vert u\vert \vert _1 \end{align} $$ (7) 其中, $S$是软阈值算子, 定义如下:
$$ \begin{equation} S(a, z)=\left\{\begin{array}{ll} a-z, &a>z \\ a+z, &a<-z \\ 0, &a\in [-z, z] \\ \end{array}\right. \end{equation} $$ (8) 整个迭代求解过程为:
输入.数据$X\in {\bf R}^{n\times p}, {y}\in {\bf R}^n$, 初始化$w^{(0)}$.
输出.参数$w^\ast ={\rm argmin}_w\textstyle{1 \over n}\vert \vert Xw-{y}\vert \vert ^2+\\ \lambda \vert\vert w\vert \vert _1 $.
1) 初始化循环次数$t = 0$;
2) 计算梯度$\nabla g=X^\mathrm{T}(Xw-{y})$;
3) 选择一个步长大小$\alpha ^t$;
4) 更新$w\leftarrow S(w-\alpha ^tg, \alpha ^t\lambda )$;
5) 判断是否收敛或者达到最大迭代次数, 未收敛$t\leftarrow t+1$, 并循环2)$\sim$5)步.
通过上述迭代计算, 最终得到最优参数, 而参数大小位于软区间中的, 将被置为零, 即被稀疏掉.
1.4 建立淋巴结转移影像组学标签与预测模型
本文使用LLR对组学特征进行降维并建模, 并使用10折交叉验证, 提高模型的泛化能力, 流程如图 3所示.
将本文使用的影像组学模型的预测概率(Radscore)作为独立的生物标志物, 并与临床指标中显著的特征结合构建多元Logistics模型, 绘制个性化预测的诺模图, 最后通过校正曲线来观察预测模型的偏移情况.
2. 结果
2.1 数据单因素分析结果
我们分别在训练集和验证集上计算各个临床指标与淋巴结转移的单因素P值, 计算方式为卡方检验, 结果见表 1, 发现吸烟与否和EGFR (Epidermal growth factor receptor)基因突变状态与淋巴结转移显著相关.
表 1 训练集和测试集病人的基本情况Table 1 Basic information of patients in the training set and test set基本项 训练集($N=400$) $P$值 测试集($N=164$) $P$值 性别 男 144 (36 %) 0.896 78 (47.6 %) 0.585 女 256 (64 %) 86 (52.4 %) 吸烟 是 126 (31.5 %) 0.030* 45 (27.4 %) 0.081 否 274 (68.5 %) 119 (72.6 %) EGFR 缺失 36 (9 %) 4 (2.4 %) 突变 138 (34.5 %) $ < $0.001* 67 (40.9 %) 0.112 正常 226 (56.5 %) 93 (56.7 %) 2.2 淋巴结转移影像组学标签
影像组学得分是每个病人最后通过模型预测后的输出值, 随着特征数的动态变化, 模型输出的AUC (Area under curve)值也随之变化, 如图 4所示, 使用R语言的Glmnet库可获得模型的参数$\lambda $的变化图.图中直观显示了参数$\lambda $的变化对模型性能的影响, 这次实验中模型选择了3个变量.如图 5所示, 横坐标表示$\lambda $的变化, 纵坐标表示变量的系数变化, 当$\lambda $逐渐变大时, 变量的系数逐渐减少为零, 表示变量选择的过程, 当$\lambda $越大表示模型的压缩程度越大.
通过套索回归方法, 自动的将变量压缩为3个, 其性能从图 4中也可发现, 模型的AUC值为最佳, 最终的特征如表 2所示. $V0$为截距项; $V179$为横向小波分解90度共生矩阵Contrast特征; $V230$为横向小波分解90度共生矩阵Entropy特征.
表 2 Lasso选择得到的参数Table 2 Parameters selected by LassoLasso选择的参数 含义 数值 $P$值 $V0$ 截距项 2.079115 $V179$ 横向小波分解90度共生矩阵Contrast特征(Contrast_2_90) 0.0000087 < 0.001*** $V230$ 横向小波分解90度共生矩阵Entropy特征(Entropy_3_180) $-$3.573315 < 0.001*** $V591$ 表面积与体积的比例(Surface to volume ratio) $-$1.411426 < 0.001*** $V591$为表面积与体积的比例; 将三个组学特征与$N$分期进行单因素分析, 其$P$值都是小于0.05, 表示与淋巴结转移有显著相关性.根据Lasso选择后的三个变量建立Logistics模型并计算出Rad-score, 详见式(9).并且同时建立SVM (Support vector machine)模型.
NB (Naive Bayesian)模型, 进行训练与预测, LLR模型训练集AUC为0.710, 测试集为0.712, 表现较优; 如表 3所示.将实验中使用的三个机器学习模型的结果进行对比, 可以发现, LLR的实验结果是最好的.
表 3 不同方法对比结果Table 3 Comparison results of different methods方法 训练集(AUC) 测试集(AUC) 召回率 LLR 0.710 0.712 0.75 SVM 0.698 0.654 0.75 NB 0.718 0.681 0.74 $$ \begin{equation} \begin{aligned} &\text{Rad-score}=2.328373+{\rm Contrast}\_2\_90\times\\ &\qquad 0.0000106 -{\rm entropy}\_3\_180\times 3.838207 +\\ &\qquad\text{Maximum 3D diameter}\times 0.0000002 -\\ &\qquad\text{Surface to volume ratio}\times 1.897416 \\ \end{aligned} \end{equation} $$ (9) 2.3 诺模图个性化预测模型
为了体现诺模图的临床意义, 融合Rad-score, 吸烟情况和EGFR基因因素等有意义的变量进行分析, 绘制出个性化预测的诺模图, 如图 7所示.为了给每个病人在最后得到一个得分, 需要将其对应变量的得分进行相加, 然后在概率线找到对应得分的概率, 从而实现非小细胞肺癌淋巴结转移的个性化预测.我们通过一致性指数(Concordance index, $C$-index)对模型进行了衡量, 其对应的$C$-index为0.724.
本文中使用校正曲线来验证诺模图的预测效果, 如图 8所示, 由校正曲线可以看出, 预测结果基本上没有偏离真实标签的结果, 表现良好, 因此, 该模型具有可靠的预测性能[15].
3. 结论
在构建非小细胞肺癌淋巴结转移的预测模型中, 使用LLR筛选组学特征并构建组学标签, 并与显著的临床特征构建多元Logistics模型, 绘制个性化预测的诺模图.其中LLR模型在训练集上的AUC值为0.710, 在测试集上的AUC值为0.712, 利用多元Logistics模型绘制个性化预测的诺模图, 得到模型表现能力$C$-index为0.724 (95 % CI: 0.678 $\sim$ 0.770), 并且在校正曲线上表现良好, 所以个性化预测的诺模图在临床决策上可起重要参考意义.[16].
-
表 1 数学符号说明
Table 1 Explanation of mathematical symbols
符号 说明 $ U=\left\{{u}_{1},\;{u}_{2},\;{\cdots ,\;u}_{n}\right\} $ 用户集合 $ V=\left\{{v}_{1},\;{v}_{2},\;{\cdots ,\;v}_{m}\right\} $ 项目集合 $ G=\left\{{g}_{1},\;{g}_{2},\;{\cdots ,\;g}_{s}\right\} $ 群组集合 $ \mathit{A}={\left[{a}_{li}\right]}_{s\times m} $ $ \langle $群组−项目$\rangle $交互矩阵 $ \mathit{B}={\left[{b}_{ij}\right]}_{n\times m} $ $ \langle $用户−项目$\rangle $交互矩阵 $ \mathit{C}={\left[{c}_{lj}\right]}_{s\times n} $ $ \langle $群组−用户$\rangle $交互矩阵 $ {\mathcal{G}}_{UV} $ $\langle $用户−项目$\rangle $交互图 $ {R}_{V}\left(u\right) $ 与用户$ u $有过交互的所有项目集合 $ \mathscr{p} $ 元路径 $ {\mathcal{N}}^{\mathscr{p}}\left(u\right) $ 节点$ u $基于元路径$ \mathscr{p} $找到的近邻集合 $ {u}_{t}^{g} $ 群组$ g $中的第$ t $个成员, $ {u}_{t}^{g}\in U $ $ f:V\to \mathbf{R} $ 由项目集到实数域的函数 (映射) $ f $ $ {\boldsymbol{e}}_{u},\;{\boldsymbol{e}}_{v},\;{\boldsymbol{e}}_{g} $ 用户$ u $, 项目$ v $和群组$ g $的ID嵌入向量 $ {\boldsymbol{h}}_{u},\;{\boldsymbol{h}}_{v},\;{\boldsymbol{h}}_{g} $ $ {\boldsymbol{e}}_{u},\;{\boldsymbol{e}}_{v},\;{\boldsymbol{e}}_{g} $ 经过编码后的向量表示 表 2 群组偏好表示学习方法对比
Table 2 Comparison of learning methods for group preference representation
表示学习层技术 特点 不足 基于启发式聚合策略的群组偏好表示方法 结合个性化推荐方法和预定义的聚合策略完成群组推荐任务, 方法简单高效 无法根据交互数据自身的模式来学习成员之间、成员与群组之间的影响力 基于概率模型的群组偏好表示方法 建模群组的生成过程, 采用潜变量表示用户对群组或其他成员的影响力 较依赖于先验分布的假设, 无法动态地建模成员用户的影响力 基于注意力机制的群组偏好表示方法 采用注意力机制主动从用户交互记录等信息中学习成员的影响力 数据稀疏性可能导致模型训练低效, 使得学习到的影响力不准确 基于图神经网络的群组偏好表示方法 采用图神经网络建模用户、群组和项目之间的高阶交互关系, 并结合注意力算子计算信息沿着关系传播的权重, 有效缓解因数据稀疏导致推荐效果不佳的问题 可能需要用户的社交信息来构建网络, 较难实现; 针对冷启动群组, 需要重新训练网络 增加约束类的群组偏好表示方法 采用增加约束的方式降低解空间的规模, 基于多任务之间的共性特征, 提升模型优化的效果 较依赖于预训练数据集的质量; 较依赖于任务之间的关联强度 引入外部信息的群组偏好表示方法 通过引入外部信息的方式, 增强群组偏好的表示学习, 如社交网络信息、项目描述信息和用户评论信息等 外部信息较难获取等问题 表 3 群组推荐数据集信息
Table 3 Information of group recommendation dataset
数据集 类别 内容 CAMRa2011[46, 48−49, 54, 62, 66] 电影 包含602个用户组成的290个群组对 7 710 部电影的评分.MovieLens 1M[31, 47, 49, 53−54, 67] 电影 包含上百万评分记录的电影数据集, 由于该数据集不存在显式的群组, 通常根据用户相似度构建群组. Weeplaces[55, 60] 签到 由于该数据集中不存在显式的群组, 通常将15 min以内在同一地点签到且存在朋友关系的用户视为一个群组, 形成包含8 643个用户打卡25 081个商户的22 733个群组. Yelp[32, 53, 55, 60, 68−69] 点评 包含34 504个用户对22 611个餐厅的点评. 由于该数据集不存在显式的群组, 将在同一时间段内打卡同一个餐厅且存在社交关系的用户视为一个群组, 形成24 103个群组. Douban[32, 55, 60, 63, 68−69] 活动 包含70 743个用户对60 028个活动的评分. 由于该数据集不存在显式的群组, 将参加同一活动的用户视为一个群组, 形成109 538个群组. Meetup[31, 47−48, 52, 63, 70] 活动 按照事件的地点, 该数据集分为Meetup-NYC (纽约市) 和Meetup-Cal (加利福尼亚). 这两个数据集均没有显式的群组, 通常将参加同一个事件的人视为一个群组. 其中, Meetup-NYC包含46 619个用户、 9428 个群组、2 326个项目. Meetup-Cal包含59 486个用户、15 207个群组、4 472个项目.BookCrossing[67] 书籍 包含 278 858个用户, 提供271 379本书的1 149 780个评分. 该数据集不包含显式的群组, 通常通过寻找相似用户构建群组. Jester Joke[71] 笑话 包含73 421个用户对 100 个笑话进行的 410 万次评分, 评分范围是 −10 ~ 10 的连续实数. 不包含分组信息, 通过计算用户相似度来进行分组. Netflix[72] 电影 包含480 507个用户对 17 770 部电影的100 480 507条评价数据, 其中评分以5分制为基准. 不包含分组信息, 利用用户的偏好相似信息构造群组.表 4 不同表示层算法在三个常见的持续性群组数据集上的推荐效果 (%)
Table 4 The recommendation performance of different presentation layer algorithms on three common persistent group datasets (%)
方法 数据集 CAMRa2011 MS MR H@5 H@10 N@5 N@10 H@5 H@10 N@5 N@10 H@5 H@10 N@5 N@10 NCF-AVG 58.33 77.65 39.69 46.25 59.19 83.15 47.35 52.21 63.52 78.42 45.32 50.29 NCF-LM 57.14 77.13 39.63 45.81 63.31 81.07 45.92 51.19 63.32 78.46 45.18 50.03 NCF-MS 57.19 75.12 38.50 44.41 64.43 82.25 46.62 51.98 62.35 77.85 44.43 49.02 AGREE 58.50 77.93 40.25 46.62 65.96 83.23 47.33 52.94 64.10 79.01 45.76 50.69 MoSAN 58.73 77.51 40.24 46.31 66.41 81.77 47.02 51.63 65.21 79.75 45.23 50.54 GAME 59.09 78.64 40.23 46.70 65.97 83.22 48.38 53.25 65.55 79.32 46.41 50.10 GLIF 59.18 78.93 40.30 46.73 66.43 83.55 48.20 53.44 65.61 79.93 46.43 51.07 KGAG 59.83 79.83 40.35 47.01 66.41 83.55 49.03 54.01 65.80 79.99 46.63 51.39 HetGRec 62.31 81.95 42.33 48.90 68.32 86.15 50.24 55.39 68.01 82.20 48.32 53.39 表 5 不同算法在三个常见的临时性群组数据集上的推荐效果 (%)
Table 5 The recommendation performance of different algorithms on three common temporary group datasets (%)
方法 数据集 Weeplaces Yelp Douban R@5 R@10 N@5 N@10 R@5 R@10 N@5 N@10 R@5 R@10 N@5 N@10 NCF-AVG 20.91 29.56 11.06 12.90 21.84 29.14 15.08 16.43 35.33 43.23 22.98 24.70 NCF-LM 20.32 28.33 10.49 12.19 23.22 31.44 16.04 17.20 44.29 49.56 31.91 33.10 NCF-MS 19.75 28.72 10.74 12.65 21.38 28.22 14.50 15.08 35.36 42.10 23.04 24.51 AGREE 20.53 29.09 11.40 13.22 24.16 30.98 16.80 17.63 45.95 51.22 33.39 34.57 MoSAN 31.81 37.71 26.25 28.15 46.57 50.61 34.66 36.18 47.10 52.22 36.12 37.24 GAME 41.97 48.53 28.90 30.35 46.44 51.94 35.32 36.52 58.76 77.52 40.29 46.33 KGAG 41.50 48.42 28.96 30.54 46.35 51.87 35.23 36.47 58.64 77.49 40.25 46.29 GroupIM 41.98 48.53 30.35 31.31 48.40 52.39 35.78 36.39 63.54 78.44 45.93 52.19 GBERT 49.43 52.82 35.31 36.43 48.67 53.14 37.46 38.11 65.20 79.90 47.22 54.58 -
[1] 唐佳睿, 田然, 梁丹辉. 电商行业深度报告: 线上消费心智加深, 积极探索新消费场景 [Online], available: https://baijiahao.baidu.com/s?id=1760070652649669963&wfr=spider&for=pc, 2023-03-11Tang Jia-Rui, Tian Ran, Liang Dan-Hui. In-depth report on the E-commerce industry: Deepening online consumption mindset and actively exploring new consumption scenarios [Online], available: https://baijiahao.baidu.com/s?id=1760070652649669963&wfr=spider&for=pc, March 11, 2023 [2] 张洪磊, 李浥东, 邬俊, 陈乃月, 董海荣. 基于隐私保护的联邦推荐算法综述. 自动化学报, 2022, 48(9): 2142−2163Zhang Hong-Lei, Li Yi-Dong, Wu Jun, Chen Nai-Yue, Dong Hai-Rong. A survey on privacy-preserving federated recommender systems. Acta Automatica Sinica, 2022, 48(9): 2142−2163 [3] Yang Y, Zhang C B, Song X, Dong Z, Zhu H S, Li W J. Contextualized knowledge graph embedding for explainable talent training course recommendation. ACM Transactions on Information Systems, 2024, 42(2): Article No. 33 [4] Cheng M Y, Liu Q, Zhang W Y, Liu Z D, Zhao H K, Chen E H. A general tail item representation enhancement framework for sequential recommendation. Frontiers of Computer Science, 2024, 18(6): Article No. 186333 doi: 10.1007/s11704-023-3112-y [5] Hao B W, Yin H Z, Li C P, Chen H. Self-supervised graph learning for occasional group recommendation. International Journal of Intelligent Systems, 2022, 37(12): 10880−10902 doi: 10.1002/int.23011 [6] McCarthy J F, Anagnost T D. MusicFX: An arbiter of group preferences for computer supported collaborative workouts. In: Proceedings of the ACM Conference on Computer Supported Cooperative Work. Seattle Washington, USA: ACM, 1998. 363−372 [7] 许晓明, 梅红岩, 于恒, 李晓会. 基于偏好融合的群组推荐方法研究综述. 小型微型计算机系统, 2020, 41(12): 2500−2508 doi: 10.3969/j.issn.1000-1220.2020.12.008Xu Xiao-Ming, Mei Hong-Yan, Yu Heng, Li Xiao-Hui. Review of group recommendation methods based on preference fusion. Journal of Chinese Computer Systems, 2020, 41(12): 2500−2508 doi: 10.3969/j.issn.1000-1220.2020.12.008 [8] 张玉洁, 杜雨露, 孟祥武. 组推荐系统及其应用研究. 计算机学报, 2016, 39(4): 745−764 doi: 10.11897/SP.J.1016.2016.00745Zhang Yu-Jie, Du Yu-Lu, Meng Xiang-Wu. Research on group recommender systems and their applications. Chinese Journal of Computers, 2016, 39(4): 745−764 doi: 10.11897/SP.J.1016.2016.00745 [9] 赵海燕, 成若瑶, 陈庆奎, 曹健. 群组推荐系统: 现状与展望. 小型微型计算机系统, 2021, 42(6): 1144−1151 doi: 10.3969/j.issn.1000-1220.2021.06.004Zhao Hai-Yan, Cheng Ruo-Yao, Chen Qing-Kui, Cao Jian. Group recommender system: Current status and future trends. Journal of Chinese Computer Systems, 2021, 42(6): 1144−1151 doi: 10.3969/j.issn.1000-1220.2021.06.004 [10] Dara S, Chowdary C R, Kumar C. A survey on group recommender systems. Journal of Intelligent Information Systems, 2020, 54(2): 271−295 doi: 10.1007/s10844-018-0542-3 [11] Kompan M, Bielikova M. Group recommendations: Survey and perspectives. Computing and Informatics, 2014, 33(2): 446−476 [12] O'Connor M, Cosley D, Konstan J A, Riedl J. PolyLens: A recommender system for groups of users. ECSCW 2001. Dordrecht: Springer, 2001. 199−218 [13] Wu X X, Xiong Y, Zhang Y, Jiao Y Z, Zhang J W, Zhu Y Y, et al. ConsRec: Learning consensus behind interactions for group recommendation. In: Proceedings of the ACM Web Conference. Austin, USA: ACM, 2023. 240−250 [14] Zhu R T, Lv D T, Yu Y, Zhu R H, Zheng Z Z, Bu K, et al. LINet: A location and intention-aware neural network for hotel group recommendation. In: Proceedings of the ACM Web Conference. Austin, USA: ACM, 2023. 779−789 [15] Crossen A, Budzik J, Hammond K J. Flytrap: Intelligent group music recommendation. In: Proceedings of the 7th International Conference on Intelligent User Interfaces. San Francisco, USA: ACM, 2002. 184−185 [16] Carroll J M, Rosson M B. Paradox of the active user. In: Proceedings of the Interfacing Thought: Cognitive Aspects of Human-computer Interaction. Cambridge, USA: MIT Press, 1987. 80−111 [17] Zheng N, Li Q D, Liao S C, Zhang L M. Which photo groups should I choose? A comparative study of recommendation algorithms in Flickr. Journal of Information Science, 2010, 36(6): 733−750 doi: 10.1177/0165551510386164 [18] Liu X J, Tian Y, Ye M, Lee W C. Exploring personal impact for group recommendation. In: Proceedings of the 21st ACM International Conference on Information and Knowledge Management. Maui, USA: ACM, 2012. 674−683 [19] Yuan Q, Cong G, Lin C Y. COM: A generative model for group recommendation. In: Proceedings of the 20th ACM SIGKDD International Conference on Knowledge Discovery and Data Mining. New York, USA: ACM, 2014. 163−172 [20] Wang Q, Mao Z D, Wang B, Guo L. Knowledge graph embedding: A survey of approaches and applications. IEEE Transactions on Knowledge and Data Engineering, 2017, 29(12): 2724−2743 doi: 10.1109/TKDE.2017.2754499 [21] Chen J W, Wu J K, Wu J C, Cao X Z, Zhou S, He X N. Adap-τ: Adaptively modulating embedding magnitude for recommendation. In: Proceedings of the ACM Web Conference. Austin, USA: ACM, 2023. 1085−1096 [22] Dyer J S, Sarin R K. Group preference aggregation rules based on strength of preference. Management Science, 1979, 25(9): 822−832 doi: 10.1287/mnsc.25.9.822 [23] 吴云昌, 刘柏嵩, 王洋洋, 费晨杰. 群组推荐分析与研究综述. 电信科学, 2018, 34(12): 71−83Wu Yun-Chang, Liu Bai-Song, Wang Yang-Yang, Fei Chen-Jie. Review of group recommendation analysis and research. Telecommunications Science, 2018, 34(12): 71−83 [24] Garcia I, Pajares S, Sebastia L, Onaindia E. Preference elicitation techniques for group recommender systems. Information Sciences, 2012, 189: 155−175 doi: 10.1016/j.ins.2011.11.037 [25] Masthoff J. Group recommender systems: Combining individual models. Recommender Systems Handbook. New York: Springer, 2010. 677−702 [26] Agarwal A, Chakraborty M, Chowdary C R. Does order matter? Effect of order in group recommendation. Expert Systems With Applications, 2017, 82: 115−127 doi: 10.1016/j.eswa.2017.03.069 [27] Baltrunas L, Makcinskas T, Ricci F. Group recommendations with rank aggregation and collaborative filtering. In: Proceedings of the 4th ACM Conference on Recommender Systems. Barcelona, Spain: ACM, 2010. 119−126 [28] Yu Z W, Zhou X S, Hao Y B, Gu J H. TV program recommendation for multiple viewers based on user profile merging. User Modeling and User-Adapted Interaction, 2006, 16(1): 63−82 doi: 10.1007/s11257-006-9005-6 [29] Xuan P C, Tang Y, Wang W S. Group recommendation method based on item type proportion factor. In: Proceedings of the IEEE/ACM International Conference on Utility and Cloud Computing Companion. Zurich, Switzerland: IEEE, 2018. 376−381 [30] 毛宇佳, 刘学军, 徐新艳, 张欣. 基于子组与社会行为的缩小群组推荐列表方法. 计算机科学, 2019, 46(2): 202−209 doi: 10.11896/j.issn.1002-137X.2019.02.031Mao Yu-Jia, Liu Xue-Jun, Xu Xin-Yan, Zhang Xin. Method based on sub-group and social behavior for narrowing recommended list for groups. Computer Science, 2019, 46(2): 202−209 doi: 10.11896/j.issn.1002-137X.2019.02.031 [31] Huang Z H, Xu X, Zhu H H, Zhou M C. An efficient group recommendation model with multiattention-based neural networks. IEEE Transactions on Neural Networks and Learning Systems, 2020, 31(11): 4461−4474 doi: 10.1109/TNNLS.2019.2955567 [32] Yin H Z, Wang Q Y, Zheng K, Li Z X, Yang J L, Zhou X F. Social influence-based group representation learning for group recommendation. In: Proceedings of the 35th International Conference on Data Engineering. Macao, China: IEEE, 2019. 566−577 [33] Jameson A. More than the sum of its members: Challenges for group recommender systems. In: Proceedings of the Working Conference on Advanced Visual Interfaces. Gallipoli, Italy: ACM, 2004. 48−54 [34] Du J, Li L, Gu P, Xie Q. A group recommendation approach based on neural network collaborative filtering. In: Proceedings of the 35th International Conference on Data Engineering Workshops. Macao, China: IEEE, 2019. 148−154 [35] Quintarelli E, Rabosio E, Tanca L. Recommending new items to ephemeral groups using contextual user influence. In: Proceedings of the 10th ACM Conference on Recommender Systems. Boston, USA: USA, 2016. 285−292 [36] Quijano-Sanchez L, Recio-Garcia J A, Diaz-Agudo B. Happymovie: A facebook application for recommending movies to groups. In: Proceedings of the 23rd International Conference on Tools with Artificial Intelligence. Boca Raton, USA: IEEE, 2011. 239−244 [37] Quijano-Sánchez L, Recio-García J A, Díaz-Agudo B. Personality and social trust in group recommendations. In: Proceedings of the 22nd IEEE International Conference on Tools With Artificial Intelligence. Arras, France: IEEE, 2010. 121−126 [38] Quijano-Sanchez L, Recio-Garcia J A, Diaz-Agudo B, Jimenez-Diaz G. Social factors in group recommender systems. ACM Transactions on Intelligent Systems and Technology (TIST), 2013, 4(1): Article No. 8 [39] Hu L, Cao J, Xu G D, Cao L B, Gu Z P, Cao W. Deep modeling of group preferences for group-based recommendation. In: Proceedings of the 28th AAAI Conference on Artificial Intelligence. Québec City, Canada: AAAI, 2014. 1861−1867 [40] Bahdanau D, Cho K, Bengio Y. Neural machine translation by jointly learning to align and translate. In: Proceedings of the 3rd International Conference on Learning Representations. San Diego, USA: ICLR, 2015. 1−15 [41] Pan X R, Ge C J, Lu R, Song S J, Chen G F, Huang Z Y, et al. On the integration of self-attention and convolution. In: Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition. New Orleans, USA: IEEE, 2022. 805−815 [42] Xu H T, Zhang J, Dai L R. Differential time-frequency log-mel spectrogram features for vision transformer based infant cry recognition. In: Proceedings of the Interspeech. Incheon, South Korea: ISCA, 2022. 1963−1967 [43] Ma Z Y, Li J J, Li G H, Cheng Y J. UniTranSeR: A unified transformer semantic representation framework for multimodal task-oriented dialog system. In: Proceedings of the 60th Annual Meeting of the Association for Computational Linguistics. Dublin, Ireland: Association for Computational Linguistics, 2022. 103−114 [44] 郑建兴, 李沁文, 王素格, 李德玉. 融合属性偏好和多阶交互信息的可解释评分预测研究. 自动化学报, 2024, 50 (11): 2231−2244Zheng Jian-Xing, Li Qin-Wen, Wang Su-Ge, Li De-Yu. Research on explainable rating prediction by fusing attribute preference and multi-order interaction information. Acta Automatica Sinica, 2024, 50 (11): 2231−2244 [45] 汤文兵, 任正云, 韩芳. 基于注意力机制的协同卷积动态推荐网络. 自动化学报, 2021, 47(10): 2438−2448Tang Wen-Bing, Ren Zheng-Yun, Han Fang. Attention-based collaborative convolutional dynamic network for recommendation. Acta Automatica Sinica, 2021, 47(10): 2438−2448 [46] Cao D, He X N, Miao L H, An Y H, Yang C, Hong R C. Attentive group recommendation. In: Proceedings of the 41st International ACM SIGIR Conference on Research and Development in Information Retrieval. Ann Arbor, USA: ACM, 2018. 645−654 [47] Tran L V, Pham T A N, Tay Y, Liu Y D, Cong G, Li X L. Interact and decide: Medley of sub-attention networks for effective group recommendation. In: Proceedings of the 42nd International ACM SIGIR Conference on Research and Development in Information Retrieval. Paris, France: ACM, 2019. 255−264 [48] He Z X, Chow C Y, Zhang J D, Li N. GRADI: Towards group recommendation using attentive dual top-down and bottom-up influences. In: Proceedings of the IEEE International Conference on Big Data. Los Angeles, USA: IEEE, 2019. 631−636 [49] Zhang S, Zheng N, Wang D L. A novel attention-based global and local information fusion neural network for group recommendation. Machine Intelligence Research, 2022, 19(4): 331−346 doi: 10.1007/s11633-022-1336-1 [50] McPherson M, Smith-Lovin L, Cook J M. Birds of a feather: Homophily in social networks. Annual Review of Sociology, 2001, 27: 415−444 doi: 10.1146/annurev.soc.27.1.415 [51] Liang R X, Zhang Q, Wang J Q, Lu J. A hierarchical attention network for cross-domain group recommendation. IEEE Transactions on Neural Networks and Learning Systems, 2024, 35(3): 3859−3873 doi: 10.1109/TNNLS.2022.3200480 [52] He Z X, Chow C Y, Zhang J D. GAME: Learning graphical and attentive multi-view embeddings for occasional group recommendation. In: Proceedings of the 43rd International ACM SIGIR Conference on Research and Development in Information Retrieval. ACM, 2020. 649−658He Z X, Chow C Y, Zhang J D. GAME: Learning graphical and attentive multi-view embeddings for occasional group recommendation. In: Proceedings of the 43rd International ACM SIGIR Conference on Research and Development in Information Retrieval. ACM, 2020. 649−658 [53] Deng Z Y, Li C Y, Liu S J, Ali W, Shao J. Knowledge-aware group representation learning for group recommendation. In: Proceedings of the 37th International Conference on Data Engineering. Chania, Greece: IEEE, 2021. 1571−1582 [54] Zhang S, Zheng N, Wang D L. HetGRec: Heterogeneous graph attention network for group recommendation. IEEE Intelligent Systems, 2023, 38(1): 9−18 doi: 10.1109/MIS.2022.3211074 [55] Sankar A, Wu Y H, Wu Y H, Zhang W, Yang H, Sundaram H. Groupim: A mutual information maximization framework for neural group recommendation. In: Proceedings of the 43rd International ACM SIGIR Conference on Research and Development in Information Retrieval. ACM, 2020. 1279−1288Sankar A, Wu Y H, Wu Y H, Zhang W, Yang H, Sundaram H. Groupim: A mutual information maximization framework for neural group recommendation. In: Proceedings of the 43rd International ACM SIGIR Conference on Research and Development in Information Retrieval. ACM, 2020. 1279−1288 [56] Veličković P, Fedus W, Hamilton W L, Liò P, Bengio Y, Hjelm R D. Deep graph infomax. In: Proceedings of the 7th International Conference on Learning Representations. New Orleans, USA: OpenReview.net, 2019. 1−17 [57] Devlin J, Chang M W, Lee K, Toutanova K. BERT: Pre-training of deep bidirectional transformers for language understanding. In: Proceedings of the Conference of the North American Chapter of the Association for Computational Linguistics: Human Language Technologies. Minneapolis, Minnesota: Association for Computational Linguistics, 2019. 4171−4186 [58] Radford A, Narasimhan K, Salimans T, Sutskever H. Improving language understanding by generative pre-training [Online], available: https://api.semanticscholar.org/CorpusID:49313245, December 18, 2023Radford A, Narasimhan K, Salimans T, Sutskever H. Improving language understanding by generative pre-training [Online], available: https://api.semanticscholar.org/CorpusID:49313245, December 18, 2023 [59] Radford A, Wu J, Child R, Luan D, Amodei D, Sutskever I. Language models are unsupervised multitask learners. OpenAI Blog, 2019, 1(8): Article No. 9 [60] Zhang S, Zheng N, Wang D L. GBERT: Pre-training user representations for ephemeral group recommendation. In: Proceedings of the 31st ACM International Conference on Information and Knowledge Management. Atlanta, USA: ACM, 2022. 2631−2639 [61] Zhang Y Y, Wu X, Fang Q, Qian S S, Xu C S. Knowledge-enhanced attributed multi-task learning for medicine recommendation. ACM Transactions on Information Systems, 2023, 41(1): Article No. 17 [62] Cao D, He X N, Miao L H, Xiao G Y, Chen H, Xu J. Social-enhanced attentive group recommendation. IEEE Transactions on Knowledge and Data Engineering, 2021, 33(3): 1195−1209 doi: 10.1109/TKDE.2019.2936475 [63] Yin H Z, Wang Q Y, Zheng K, Li Z X, Zhou X F. Overcoming data sparsity in group recommendation. IEEE Transactions on Knowledge and Data Engineering, 2022, 34(7): 3447−3460 [64] Chen H X, Yin H Z, Chen T, Nguyen Q V H, Peng W C, Li X. Exploiting centrality information with graph convolutions for network representation learning. In: Proceedings of the 35th International Conference on Data Engineering. Macao, China: IEEE, 2019. 590−601 [65] He X N, Liao L Z, Zhang H W, Nie L Q, Hu X, Chua T S. Neural collaborative filtering. In: Proceedings of the 26th International Conference on World Wide Web. Perth, Australia: International World Wide Web Conferences Steering Committee, 2017. 173−182 [66] Feng S S, Zhang H X, Wang L, Liu L, Xu Y C. Detecting the latent associations hidden in multi-source information for better group recommendation. Knowledge-Based Systems, 2019, 171: 56−68 doi: 10.1016/j.knosys.2019.02.002 [67] Choudhary N, Minz S, Bharadwaj K K. Negotiation framework for group recommendation based on fuzzy computational model of trust and distrust. Multimedia Tools and Applications, 2020, 79(37−38): 27337−27364 doi: 10.1007/s11042-020-09339-x [68] Guo L, Yin H Z, Wang Q Y, Cui B, Huang Z, Cui L Z. Group recommendation with latent voting mechanism. In: Proceedings of the 36th International Conference on Data Engineering. Dallas, USA: IEEE, 2020. 121−132 [69] Guo L, Yin H Z, Chen T, Zhang X L, Zheng K. Hierarchical hyperedge embedding-based representation learning for group recommendation. ACM Transactions on Information Systems (TOIS), 2021, 40(1): Article No. 3 [70] Seo Y D, Kim Y G, Lee E, Seol K S, Baik D K. An enhanced aggregation method considering deviations for a group recommendation. Expert Systems With Applications, 2018, 93: 299−312 doi: 10.1016/j.eswa.2017.10.027 [71] Loveymi S, Hamzeh A. Proposing an evolutionary method based on maximization precision of group recommender systems. In: Proceedings of the 7th Conference on Information and Knowledge Technology. Urmia, Iran: IEEE, 2015. 1−6 [72] Guo Z W, Tang C W, Tang H, Fu Y Q, Niu W J. A novel group recommendation mechanism from the perspective of preference distribution. IEEE Access, 2018, 6: 5865−5878 doi: 10.1109/ACCESS.2018.2792427 [73] Sun Y Z, Han J W, Yan X F, Yu P S, Wu T Y. PathSim: Meta path-based top-k similarity search in heterogeneous information networks. Proceedings of the VLDB Endowment, 2011, 4(11): 992−1003 doi: 10.14778/3402707.3402736 [74] Zeng Z N, Xiao C J, Yao Y, Xie R B, Liu Z Y, Lin F, et al. Knowledge transfer via pre-training for recommendation: A review and prospect. Frontiers in Big Data, 2021, 4: Article No. 602071 doi: 10.3389/fdata.2021.602071 [75] Jafri S I H, Ghazali R, Javid I, Mahmood Z, Hassan A A A. Deep transfer learning with multimodal embedding to tackle cold-start and sparsity issues in recommendation system. PLoS One, 2022, 17(8): 1−24 [76] Gan M X, Ma Y X. Knowledge transfer learning from multiple user activities to improve personalized recommendation. Soft Computing, 2022, 26(14): 6547−6566 doi: 10.1007/s00500-022-07178-6 [77] Chen J W, Dong H D, Qiu Y, He X N, Xin X, Chen L, et al. AutoDebias: Learning to debias for recommendation. In: Proceedings of the 44th International ACM SIGIR Conference on Research and Development in Information Retrieval. ACM, 2021. 21−30Chen J W, Dong H D, Qiu Y, He X N, Xin X, Chen L, et al. AutoDebias: Learning to debias for recommendation. In: Proceedings of the 44th International ACM SIGIR Conference on Research and Development in Information Retrieval. ACM, 2021. 21−30 [78] Chen J W, Dong H D, Wang X, Feng F L, Wang M, He X N. Bias and debias in recommender system: A survey and future directions. ACM Transactions on Information Systems, 2023, 41(3): Article No. 67 [79] Chawla N V, Bowyer K W, Hall L O, Kegelmeyer W P. SMOTE: Synthetic minority over-sampling technique. Journal of Artificial Intelligence Research, 2002, 16(1): 321−357 [80] Mandal P, Samanta S, Pal M, Ranadive A S. Pythagorean linguistic preference relations and their applications to group decision making using group recommendations based on consistency matrices and feedback mechanism. International Journal of Intelligent Systems, 2020, 35(5): 826−849 doi: 10.1002/int.22226 [81] Castro J, Quesada F J, Palomares I, Martínez L. A consensus-driven group recommender system. International Journal of Intelligent Systems, 2015, 30(8): 887−906 doi: 10.1002/int.21730 [82] Garcia I, Sebastia L. A negotiation framework for heterogeneous group recommendation. Expert Systems With Applications, 2014, 41(4): 1245−1261 doi: 10.1016/j.eswa.2013.07.111 [83] Xu Y S, Zhang Y X, Guo W, Guo H F, Tang R M, Coates M. GraphSAIL: Graph structure aware incremental learning for recommender systems. In: Proceedings of the 29th ACM International Conference on Information and Knowledge Management. ACM, 2020. 2861−2868Xu Y S, Zhang Y X, Guo W, Guo H F, Tang R M, Coates M. GraphSAIL: Graph structure aware incremental learning for recommender systems. In: Proceedings of the 29th ACM International Conference on Information and Knowledge Management. ACM, 2020. 2861−2868 [84] Song L Q, Tekin C, van der Schaar M. Online learning in large-scale contextual recommender systems. IEEE Transactions on Services Computing, 2016, 9(3): 433−445 doi: 10.1109/TSC.2014.2365795 [85] Zheng N, Li Q D. A recommender system based on tag and time information for social tagging systems. Expert Systems With Applications, 2011, 38(4): 4575−4587 doi: 10.1016/j.eswa.2010.09.131 [86] Lin J H, Dai X Y, Xi Y J, Liu W W, Chen B, Li X Y, et al. How can recommender systems benefit from large language models: A survey. ACM Transactions on Information Systems, DOI: 10.1145/3678004 [87] Wu L K, Zheng Z, Qiu Z P, Wang H, Gu H C, Shen T J, et al. A survey on large language models for recommendation. World Wide Web, 2024, 27(5): Article No. 60 doi: 10.1007/s11280-024-01291-2 [88] Li L, Zhang Y F, Liu D G, Chen L. Large language models for generative recommendation: A survey and visionary discussions. In: Proceedings of the Joint International Conference on Computational Linguistics, Language Resources and Evaluation. Torino, Italia: ELRA and ICCL, 2023. 10146−10159 [89] Qiu Z P, Wu X, Gao J Y, Fan W. U-BERT: Pre-training user representations for improved recommendation. In: Proceedings of the 35th AAAI Conference on Artificial Intelligence. AAAI, 2021. 4320−4327Qiu Z P, Wu X, Gao J Y, Fan W. U-BERT: Pre-training user representations for improved recommendation. In: Proceedings of the 35th AAAI Conference on Artificial Intelligence. AAAI, 2021. 4320−4327 -
