基于非线性干扰观测器的飞机全电刹车系统滑模控制设计

李繁飙; 黄培铭; 阳春华; 廖力清; 桂卫华

doi:10.16383/j.aas.c201041

基于非线性干扰观测器的飞机全电刹车系统滑模控制设计

doi: 10.16383/j.aas.c201041

李繁飙^{1, 2,},
黄培铭^1,,
阳春华^1,,
廖力清^1,,
桂卫华^1,

1.
中南大学自动化学院长沙 410083
2.
鹏城实验室深圳 518000

基金项目: 国家自然科学基金(61973319), 湖南省优秀青年基金(2019JJ30032), 机器人技术与系统国家重点实验室开放基金(SKLRS-2020-KF-14)资助

详细信息

作者简介:
李繁飙：中南大学自动化学院教授. 2015年获得哈尔滨工业大学控制科学与工程博士学位. 主要研究方向为复杂工业过程智能控制与优化, 非连续控制理论. E-mail: fanbiaoli@csu.edu.cn

黄培铭：中南大学自动化学院硕士研究生. 主要研究方向为飞机刹车系统建模与控制. E-mail: peiming_huang@csu.edu.cn

阳春华：中南大学自动化学院教授. 2002年获得中南大学博士学位. 主要研究方向为复杂工业过程建模与优化, 故障诊断和智能系统. E-mail: ychh@csu.edu.cn

廖力清：中南大学自动化学院教授. 2010年获得中南大学博士学位. 主要研究方向为电力电子与电力传动, 电力系统自动化, 飞机起飞着陆系统智能控制. 本文通信作者. E-mail: zdh-dqkz@csu.edu.cn

桂卫华：中国工程院院士, 中南大学自动化学院教授. 1981年获得中南矿冶学院硕士学位. 主要研究方向为复杂工业过程建模, 优化与控制应用, 故障诊断与分布式鲁棒控制. E-mail: gwh@csu.edu.cn

计量
- 文章访问数: 2202
- HTML全文浏览量: 549
- PDF下载量: 560
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-18
- 网络出版日期: 2021-06-28
- 刊出日期: 2021-11-18

Sliding Mode Control Design of Aircraft Electric Brake System Based on Nonlinear Disturbance Observer

1.
School of Automation, Central South University, Changsha 410083
2.
Peng Cheng Laboratory, Shenzhen 518000

Funds: Supported by National Natural Science Foundation of China (61973319), Excellent Youth Natural Science Foundation of Hunan Province (2019JJ30032), State Key Laboratory of Robotics and Systems (HIT) (SKLRS-2020-KF-14)

More Information

Author Bio:
LI Fan-Biao　Professor at the School of Automation, Central South University. He received his Ph. D. degree from Harbin Institute of Technology in 2015. His research interest covers intelligent control and optimization of complex industrial processes, discontinuous control theory

HUANG Pei-Ming　Master student at the School of Automation, Central South University. His research interest covers aircraft braking system modeling and control

YANG Chun-Hua　Professor at the School of Automation, Central South University. She received her Ph. D. degree from Central South University in 2002. Her research interest covers complex industrial process modeling and optimization, fault diagnosis, and intelligent system

LIAO Li-Qing　Professor at the School of Automation, Central South University. He received his Ph. D. degree from Central South University in 2010. His research interest covers power electronics and power transmission, power system automation, and intelligent control of aircraft take-off and landing system. Corresponding author of this paper

GUI Wei-Hua　Academician of the Chinese Academy of Engineering, and professor at the School of Automation, Central South University. He received his master degree from Central South Institute of Mining and Metallurgy in 1981. His research interest covers complex industrial process modeling, optimization and control applications, fault diagnosis and distribute robust control

摘要

摘要: 飞机防滑刹车具有典型的强非线性、强耦合和参数时变等特点, 并且跑道环境的干扰容易对飞机的地面滑跑性能造成不利影响. 本文提出了一种基于非线性干扰观测器的飞机全电防滑刹车系统滑模控制设计方法. 首先, 考虑了实际刹车不确定性干扰条件下的防滑刹车动力学建模问题, 通过对高阶非线性刹车系统进行反馈线性化处理, 简化了基于严格反馈的模型. 其次, 基于对主轮打滑原因的深入分析, 设计了非线性干扰观测器对干扰进行在线估计, 并在控制律设计中引入补偿部分. 通过构造递归结构的快速终端滑模控制器来跟踪实时变化的最佳滑移率并建立稳定性条件, 实现了飞机全电防滑刹车系统的有限时间快速稳定并有效抑制了主轮锁定打滑. 通过在不同跑道状态下进行模拟仿真, 验证了本文提出的飞机防滑刹车控制策略可以有效地提高刹车效率.
- 飞机防滑刹车系统 /
- 终端滑模控制 /
- 非线性干扰观测器 /
- 反馈线性化
Abstract: Aircraft antiskid braking has typical characteristics of strong nonlinearity, strong coupling and time-varying parameters, and the disturbance of runway environment is easy to adversely affect the ground running performance of the aircraft. In this paper, a nonlinear disturbance observer-based sliding mode control design method is proposed for the aircraft electric antiskid braking system. Firstly, the dynamic modeling problem of antiskid braking under the disturbance of actual braking uncertainty is considered. The model based on strict feedback is simplified in the light of feedback linearization of the high-order nonlinear braking system. Secondly, based on the in-depth analysis of the main wheel slip, a nonlinear disturbance observer is designed to estimate the disturbance online, and the compensation part is introduced into the control law design process. A fast terminal sliding mode controller with recursive structure is constructed to track the optimal sliding rate changing in real time and the stability conditions have been established. The finite-time stability of the aircraft all-electric antiskid braking system is realized and the locking slip of the main wheel is effectively suppressed. Simulation results show that the antiskid braking control strategy proposed in this paper can effectively improve braking efficiency.
- Aircraft antiskid braking system /
- terminal sliding mode control /
- nonlinear disturbance observer /
- feedback linearization

HTML全文

图 1 飞机机体受力图

Fig. 1 Force diagram of aircraft fuselage

下载: 全尺寸图片幻灯片

图 2 单个主轮受力分析图

Fig. 2 Force analysis diagram of single main wheel

下载: 全尺寸图片幻灯片

图 3 干沥青跑道摩擦系数模型曲线

Fig. 3 Curve of friction coefficient model on dry asphalt runway

下载: 全尺寸图片幻灯片

图 4 ${v_x}$ = 30 m/s不同跑道状态$\mu $-$\lambda $曲线

Fig. 4 Curve of $\mu $-$\lambda $ on the different runway conditions with ${v_x}$= 30 m/s

下载: 全尺寸图片幻灯片

图 5 $\lambda $与$\mu $关系曲线

Fig. 5 Relational between $\lambda $ and $\mu $

下载: 全尺寸图片幻灯片

图 6 飞机防滑刹车闭环控制总框图

Fig. 6 General block diagram of aircraft antiskid brake closed-loop control

下载: 全尺寸图片幻灯片

图 7 干扰观测仿真结果

Fig. 7 Simulation results of disturbance observation

下载: 全尺寸图片幻灯片

图 8 干沥青跑道状态下两种控制方法的飞机防滑刹车控制仿真结果

Fig. 8 Simulation results of aircraft antiskid brake control with two control methods under dry asphalt runway condition

下载: 全尺寸图片幻灯片

图 9 雪跑道状态下飞机防滑刹车控制仿真结果

Fig. 9 Simulation results of aircraft antiskid brake control under snow runway condition

下载: 全尺寸图片幻灯片

表 1 飞机防滑刹车系统参数

Table 1 Parameters of antiskid braking system

参数	具体描述
$m$	飞机质量
${v_x}$	飞机纵向滑跑速度
${F_x}$	迎风阻力
${F_y}$	飞机升力
${F_{f1}}$	单个主轮与地面间摩擦力
${F_{f2}}$	单个前轮与地面间摩擦力
${n_1}$	受刹主轮个数
${n_2}$	前轮个数
${T_v}$	发动机推力
${N_1}$	单个主轮垂直载荷
${N_2}$	单个前轮垂直载荷
$g$	重力加速度
$a$	前轮中心与飞机重心的水平距离
$b$	主轮中心与飞机重心的水平距离
$h$	飞机重心与地面的垂直高度
${h_t}$	发动机推力点与飞机重心的垂直高度
${T_{{\rm{int}} }}$	发动机剩余推力
${k_x}$	纵向空气阻力系数
${k_y}$	横向空气阻力系数
$\rho $	空气密度
${C_d}$	飞机气动阻力系数
${C_L}$	飞机滑跑时的升力系数
${S_w}$	机翼总面积

下载: 导出CSV

表 2 摩擦系数模型参数

Table 2 Parameters of friction coefficient model

跑道状态	${c_1}$	${c_2}$	${c_3}$	${c_4}$
干沥青	1.2801	23.99	0.52	0.04
干混凝土	1.1973	25.168	0.5373	0.04
湿沥青	0.857	33.822	0.347	0.04
雪	0.1946	94.129	0.0646	0.04
冰	0.05	306.39	0	0.04

下载: 导出CSV

表 3 飞机防滑刹车性能指标

Table 3 Aircraft antiskid brake performance index

性能指标	干沥青	雪
刹车距离 (m)	496.807	2060.411
刹车时间 (s)	11.82	53.92
跟踪效率 (%)	99.43	98.95
制动效率 (%)	99.66	99.17

下载: 导出CSV

表 4 两种控制方法性能对比

Table 4 Performance comparison of the two control methods

对比项目	递归型	传统型
机轮仅工作在稳定区	是	否
最佳滑移率和最大摩擦系数的稳态误差	无	有
暂态至稳态的快速性	较快	较慢
鲁棒性	较强	较弱

下载: 导出CSV
