基于深度强化学习的双足机器人斜坡步态控制方法

吴晓光; 刘绍维; 杨磊; 邓文强; 贾哲恒

doi:10.16383/j.aas.c190547

基于深度强化学习的双足机器人斜坡步态控制方法

doi: 10.16383/j.aas.c190547

1.
燕山大学电气工程学院秦皇岛 066004

基金项目: 国家自然科学基金(61503325), 中国博士后科学基金(2015M581316)资助

详细信息

作者简介:
吴晓光：燕山大学电气工程学院副教授, 2012年获得哈尔滨工业大学博士学位. 主要研究方向为双足机器人, 三维虚拟视觉重构. E-mail: wuxiaoguang@ysu.edu.cn

刘绍维：燕山大学电气工程学院硕士研究生. 主要研究方向为深度强化学习, 双足机器人. 本文通信作者.E-mail: lwsalpha@outlook.com

杨磊：燕山大学电气工程学院硕士研究生. 主要研究方向为双足机器人稳定性分析.E-mail: 15733513567@163.com

邓文强：燕山大学电气工程学院硕士研究生. 主要研究方向为生成对抗网络, 人体运动协调性分析.E-mail: dengwq24@163.com

贾哲恒：燕山大学电气工程学院硕士研究生. 主要研究方向为人体姿态估计, 目标识别, 深度学习.E-mail: jiazheheng@163.com

计量
- 文章访问数: 6013
- HTML全文浏览量: 2288
- PDF下载量: 760
- 被引次数: 0
出版历程
- 收稿日期: 2019-07-23
- 录用日期: 2020-01-09
- 网络出版日期: 2021-08-25
- 刊出日期: 2021-08-20

A Gait Control Method for Biped Robot on Slope Based on Deep Reinforcement Learning

1.
School of Electrical Engineering, Yanshan University, Qinhuangdao 066004

Funds: Supported by National Natural Science Foundation of China (61503325), China Postdoctoral Science Foundation under Grants (2015M581316)

More Information

Author Bio:
WU Xiao-Guang　Associate professor at the School of Electrical Engineering, Yanshan University. He received his Ph. D. degree in 2012 from Harbin University of Technology. His research interest covers biped robot and 3D virtual vision reconstruction

LIU Shao-Wei　Master student at the School of Electrical Engineering, Yanshan University. His research interest covers deep reinforcement learning, biped robot. Corresponding author of this paper

YANG Lei　Master student at the School of Electrical Engineering, Yanshan University. His main research interest is stability analysis of biped robot

DENG Wen-Qiang　Master student at the School of Electrical Engineering, Yanshan University. His research interest covers generating confrontation networks and the analysis of human motion coordination

JIA Zhe-Heng　Master student at the School of Electrical Engineering, Yanshan University. His research interest covers human pose estimation, object detection, and deep learning

摘要

摘要:
为提高准被动双足机器人斜坡步行稳定性, 本文提出了一种基于深度强化学习的准被动双足机器人步态控制方法. 通过分析准被动双足机器人的混合动力学模型与稳定行走过程, 建立了状态空间、动作空间、episode过程与奖励函数. 在利用基于DDPG改进的Ape-X DPG算法持续学习后, 准被动双足机器人能在较大斜坡范围内实现稳定行走. 仿真实验表明, Ape-X DPG无论是学习能力还是收敛速度均优于基于PER的DDPG. 同时, 相较于能量成型控制, 使用Ape-X DPG的准被动双足机器人步态收敛更迅速、步态收敛域更大, 证明Ape-X DPG可有效提高准被动双足机器人的步行稳定性.
- 准被动双足机器人 /
- 深度强化学习 /
- 步态控制 /
- 步行稳定性
Abstract:
In order to improve the walking stability on slope of the quasi-passive biped robot, in this paper, we proposed a gait control method for quasi-passive biped robot based on deep reinforcement learning. By analyzing the hybrid dynamics model and the stable walking process of the quasi-passive biped robot establishing the state space, action space, episode process and reward function. After learning by Ape-X DPG algorithm based on DDPG improvement, quasi-passive biped robot can achieve stable walking in a larger slope range. In the simulation, Ape-X DPG is better than DDPG + PER in both learning ability and convergence speed. Meanwhile, compared with energy shaping controller, the gait convergence of quasi-passive biped robot using Ape-X DPG is more rapid and the basins of attraction is larger, which proves that Ape-X DPG can effectively improve the walking stability of quasi-passive biped robot.
- Quasi-passive biped robot /
- deep reinforcement learning /
- gait control /
- walking stability

HTML全文

图 1 机器人模型示意图

Fig. 1 Sketch of the biped model

下载: 全尺寸图片幻灯片

图 2 被动步行过程

Fig. 2 Passive dynamic waking process

下载: 全尺寸图片幻灯片

图 3 DDPG中神经网络训练过程

Fig. 3 The neural network training process in DDPG

下载: 全尺寸图片幻灯片

图 4 Ape-X DPG算法结构

Fig. 4 The structure of Ape-X DPG

下载: 全尺寸图片幻灯片

图 5 交互单元n中Episode过程

Fig. 5 Episode process in interaction unit n

下载: 全尺寸图片幻灯片

图 6 falls = 0时的奖励函数空间

Fig. 6 Landscape of the reward function when falls = 0

下载: 全尺寸图片幻灯片

图 7 平均奖励值曲线

Fig. 7 The curves of the average reward

下载: 全尺寸图片幻灯片

图 8 测试集稳定行走次数

Fig. 8 Stable walking times in test

下载: 全尺寸图片幻灯片

图 9 机器人左腿相空间图

Fig. 9 The phase plane of the right leg

下载: 全尺寸图片幻灯片

图 10 初始状态b时机器人行走状态

Fig. 10 Biped walking state in initial state b

下载: 全尺寸图片幻灯片

图 11 机器人行走过程棍状图

Fig. 11 The gait diagrams of the biped

下载: 全尺寸图片幻灯片

图 12 机器人物理模型示意图

Fig. 12 Sketch of the biped physical model

下载: 全尺寸图片幻灯片

图 13 机器人物理仿真

Fig. 13 Robot physics simulation

下载: 全尺寸图片幻灯片

图 14 稳定行走胞数

Fig. 14 The number of the state walking

下载: 全尺寸图片幻灯片

图 15 $ \phi = 0.1 $时机器人步态收敛域

Fig. 15 The biped BOA when $ \phi = 0.1 $

下载: 全尺寸图片幻灯片

表 1 机器人符号及无量纲参数

Table 1 Symbols and dimensionless default values of biped parameters

参数	符号	数值
腿长	I	1
腿部质心	m₁	1
髋关节质心	m₂	2
足半径	r	0.3
腿部质心与圆弧足中心距离	I₁	0.55
髋关节与圆弧足中心距离	I₂	0.7
髋关节到腿部质心距离	c	0.15
腿部转动惯量	J₁	0.01
重力加速度	g	9.8

下载: 导出CSV

表 2 扰动函数N分配与学习耗时

Table 2 Noise function N settings and learning time

算法	高斯扰动	O-U 扰动	网络参数扰动^[39]	耗时
DDPG	0	1	0	6.4 h
2 交互单元	1	1	0	4.2 h
4 交互单元	2	1	1	4.2 h
6 交互单元	2	2	2	4.3 h

下载: 导出CSV

表 3 机器人初始状态

Table 3 The initial states of the biped

状态	$\theta_1$ (rad)	$\dot\theta_1$ (rad/s)	$\dot\theta_2$ (rad/s)	$\phi$
a	0.37149	−1.24226	2.97253	0.078
b	0.24678	−1.20521	0.15476	0.121

下载: 导出CSV
