基于多相关<b>HMT</b>模型的<b>DT CWT</b>域数字水印算法

王向阳; 牛盼盼; 杨红颖; 李丽

doi:10.16383/j.aas.c190075

基于多相关HMT模型的DT CWT域数字水印算法

doi: 10.16383/j.aas.c190075

1.
辽宁师范大学计算机与信息技术学院大连 116029

基金项目: 国家自然科学基金(61472171, 61701212), 中国博士后科学基金(2018T110220), 辽宁省教育厅科学研究经费项目(面上项目) (LJKZ0985), 辽宁省自然科学基金(2019-ZD-0468)资助

详细信息

作者简介:
王向阳：辽宁师范大学计算机科学与技术学院教授. 主要研究方向为网络信息安全与智能多媒体计算. 本文通信作者. E-mail: wxy37@126.com

牛盼盼：博士, 辽宁师范大学计算机与信息技术学院副教授. 主要研究方向为网络信息安全与图像处理. E-mail: niupanpan3333@163.com

杨红颖：辽宁师范大学计算机科学与技术学院教授. 主要研究方向为多媒体信息安全与图像处理. E-mail: yhy65@126.com

李丽：辽宁师范大学计算机科学与技术学院硕士研究生. 主要研究方向为信息隐藏与数字水印. E-mail: workprocess0003@163.com

计量
- 文章访问数: 884
- HTML全文浏览量: 196
- PDF下载量: 114
- 被引次数: 0
出版历程
- 收稿日期: 2019-01-30
- 录用日期: 2019-08-08
- 网络出版日期: 2021-09-09
- 刊出日期: 2021-12-23

A Blind Watermark Decoder in DT CWT Domain Using Weibull Distribution-Based Vector HMT Model

1.
School of Computer and Information Technology, Liaoning Normal University, Dalian 116029

Funds: Supported by National Natural Science Foundation of China (61472171, 61701212), Project Funded by China Postdoctoral Science Foundation (2018T110220), Scientific Research Project of Liaoning Provincial Education Department(LJKZ0985), and Natural Science Foundation of Liaoning Province (2019-ZD-0468)

More Information

Author Bio:
WANG Xiang-Yang　Professor at the Multimedia and Information Security Laboratory, School of Computer and Information Technology, Liaoning Normal University. His current research interest covers network information security, and intelligent multimedia computing. Corresponding author of this paper

NIU Pan-Pan　Ph.D., associate professor at the School of Computer and Information Technology, Liaoning Normal University. Her research interest covers network information security and image processing

YANG Hong-Ying　Professor at the School of Computer and Information Technology, Liaoning Normal University. Her current research interest covers multimedia information security and image processing

LI Li　Master student at the School of Computer and Information Technology, Liaoning Normal University. Her current research interest covers information hiding and digital watermarking

摘要

摘要: 本文以双树复数小波变换(Dual-tree complex wavelet transform, DT CWT)及隐马尔科夫树(Hidden Markov tree, HMT)理论为基础, 提出了一种基于Weibull向量HMT模型的DT CWT域数字音频盲水印算法. 原始数字音频首先进行DT CWT, 然后利用局部信息熵刻画音频内容特征并据此确定出重要DT CWT系数段, 进而将水印信息乘性嵌入到重要DT CWT高频系数幅值内. 水印检测时, 首先根据DT CWT系数幅值的边缘分布及系数间的多种相关性(包括子带内、尺度间、分解树间等相关性), 构造出Weibull混合向量HMT统计模型, 并估计出其统计模型参数; 然后, 利用局部最大势能(Locally most powerful, LMP)检验理论构造出局部最优检测器(Locally optimum decoder, LOD)以盲提取水印信息. 仿真实验结果表明, 本文算法可以较好地获得不可感知性、鲁棒性、水印容量之间的良好平衡, 其总体性能优于现有同类音频水印算法.
- 音频水印 /
- 向量隐马尔科夫树 /
- Weibull混合模型 /
- 局部信息熵 /
- 双树复数小波变换 /
- 局部最优检测器
Abstract: In this paper, we propose a blind audio watermark decoder in dual-tree complex wavelet transform (DT CWT) domain, wherein the Weibull distribution-based vector hidden Markov tree (HMT) model is used. In the proposed watermarking approach, the DT CWT is firstly performed on the original host audio, then the significant DT CWT coefficient segments are determined according to local information entropy, and finally the watermark data is embedded into the significant high-frequency coefficient amplitudes in the DT CWT domain. At the watermark receiver, DT CWT highpass coefficient amplitudes are firstly modeled by employing the Weibull distribution-based vector HMT Model, where both the local statistical properties and various dependencies of the DT CWT coefficients are captured. Then the parameters of the Weibull distribution-based vector HMT model are estimated on the highpass coefficients of digital audio using the maximum likelihood estimation (MLE). And finally, by employing locally most powerful test and the Weibull distribution-based vector HMT model, a blind local optimum decoder (LOD) is developed. We conduct extensive experiments to evaluate the performance of the proposed blind watermark decoder, in which encouraging results validate the effectiveness of the proposed technique.
- Audio watermarking /
- vector hidden Markov tree (HMT) /
- Weibull mixture model /
- local information entropy /
- dual-tree complex wavelet transform (DT CWT) /
- locally optimum decoder (LOD)
注释:

1) 收稿日期 2019-01-30 录用日期 2019-08-08 Manuscript received January 30, 2019; accepted August 8, 2019 国家自然科学基金 (61472171, 61701212), 中国博士后科学基金(2018T110220), 辽宁省教育厅科学研究经费项目 (面上项目) (LJKZ0985), 辽宁省自然科学基金 (2019-ZD-0468) 资助 Supported by National Natural Science Foundation of China (61472171, 61701212), Project Funded by China Postdoctoral Science Foundation (2018T110220), Scientific Research Project of Liaoning Provincial Education Department (LJKZ0985), and Natural Science Foundation of Liaoning Province (2019-ZD-0468) 本文责任编委刘成林 Recommended by Associate Editor LIU Cheng-Lin 1. 辽宁师范大学计算机与信息技术学院大连 116029 1. School of Computer and Information Technology, Liaoning

2) Normal University, Dalian 116029

HTML全文

图 1 DT CWT域系数幅值的子带内、尺度间、分解树间Chi-plot图

Fig. 1 Chi-plot to illustrate the different degrees of dependence between intraband, interscale and dual-tree, DT CWT coefficient pairs

下载: 全尺寸图片幻灯片

图 2 DT CWT域向量HMT模型

Fig. 2 Vector HMT model in DT CWT domain

下载: 全尺寸图片幻灯片

图 3 两种数字水印检测器(LOD和ML)的检测响应结果

Fig. 3 The test results of LOD watermark detector and ML watermark detector under various attacks

下载: 全尺寸图片幻灯片

图 4 原始音频、含水印音频和差值音频波形图

Fig. 4 The waveform of original audio, watermarked audio, and difference audio

下载: 全尺寸图片幻灯片

图 5 本文算法的鲁棒性能测试结果

Fig. 5 The watermark detection results for various attacks

下载: 全尺寸图片幻灯片

表 1 不同系数段长度下整个水印系统的工作性能 (水印容量为1 024位)

Table 1 Performance of the watermarking system in different coefficient lengths (watermark capacity is 1 024 bits)

DT CWT系数段长度	平均PSNR (dB)	平均BER (%)	平均水印嵌入时间 (s)	平均水印提取时间 (s)
40	48.45	0.29	0.45	8.42
50	47.96	0.09	0.62	9.57
60	47.28	0.00	0.71	10.67
70	46.34	0.00	1.21	11.53

下载: 导出CSV

表 2 不同水印容量下整个水印系统的工作性能(局部重要系数段长度为60)

Table 2 Performance of the watermarking system in different watermark capacities (coefficient length is 60)

水印容量 (bit)	PSNR (dB)	BER (%)	水印嵌入时间 (s)	水印提取时间 (s)
8 × 8	49.23	0.00	0.47	9.53
16 × 16	48.16	0.00	0.68	10.24
32 × 32	47.28	0.00	0.71	10.67
64 × 64	44.34	0.78	1.35	15.46

下载: 导出CSV

表 3 客观听觉测试区分度ODG

Table 3 Objective difference grades

等级	ODG	描述
5.0	0.0	不可感觉
4.0	−1.0	可感觉但不刺耳
3.0	−2.0	轻微刺耳
2.0	−3.0	刺耳
1.0	−4.0	非常刺耳

下载: 导出CSV

表 4 感知透明性与鲁棒性客观评价

Table 4 Objective evaluation of perceived transparency and robustness

音频类型	ODG	BER (%)
Popular	−0.61	0.00
Jazz	−0.48	0.03
Rock	−0.68	0.16
Speech	−0.35	0.01
Classical	−0.79	0.08

下载: 导出CSV

表 5 不同算法的平均检测性能对比(本文算法和文献[8])

Table 5 Comparison of average detection performance of different schemes (our scheme and [8])

攻击类型	本文算法	文献 [8]
攻击类型	本文算法	DWT-RDM-W+DC	DWT-RDM-W	DWT-ROM	DWT-LQIM	DWT-norm
Resampling (22 050 Hz)	0.000	0.000	0.000	0.000	0.000	0.000
Requantization (16 bit - 8 bit - 16 bit)	0.000	0.000	0.000	0.000	0.001	0.000
Amplitude scaling down to 0.85	0.000	0.000	0.000	0.000	0.000	73.723
Additive of Gaussian noise	0.000	0.002	0.006	0.003	0.006	0.000
Lowpass filtering (4 kHz)	0.000	0.219	0.262	0.290	0.376	0.184
Echo addition (50 ms delay, 5 % decay)	0.021	0.026	0.041	0.041	0.187	0.142
MP3 compression (128 kbps)	0.000	0.000	0.000	0.000	0.000	0.002
MP3 compression (64 ps)	0.000	0.152	0.169	0.211	0.256	0.258

下载: 导出CSV

表 6 不同算法的平均检测性能对比(本文算法和文献[5])

Table 6 Comparison of average detection performance of different schemes (our scheme and [5])

攻击类型	本文算法		文献 [5]
攻击类型	Classical	Popular	Classical N=8	Popular N=4	Classical N=8	Popular N=4
Resampling (22 050 Hz)	0.00	0.00	0.00	0.29	0.00	0.71
Resampling (11 025 Hz)	0.00	0.00	0.00	1.22	0.00	1.06
Resampling (8 000 Hz)	0.02	0.02	0.01	1.25	0.02	1.20
Lowpass filtering (3 kHz)	0.00	0.35	24.03	27.32	26.06	23.85
MP3 compression (128 kbps)	0.00	0.00	0.11	0.13	0.08	0.08
MP3 compression (112 kbps)	0.00	0.00	0.13	0.11	0.06	0.12
MP3 compression (96 kbps)	0.00	0.00	1.01	2.07	1.06	1.40
MP3 compression (80 kbps)	0.01	0.00	1.57	3.65	1.16	2.50

下载: 导出CSV

表 7 不同算法的平均检测性能对比(本文算法和文献[7])

Table 7 Comparison of average detection performance of different schemes (our scheme and [7])

攻击类型	−30 dB WSR		−25 dB WSR		−20 dB WSR
攻击类型	文献 [7]	本文算法	文献 [7]	本文算法	文献 [7]	本文算法
No Attack	0.14	0.00	0.04	0.00	0.00	0.00
MP3 compression (64 kbps)	32.12	10.35	25.12	0.83	17.11	0.04
MP3 compression (128 kbps)	24.22	0.33	19.54	0.04	12.01	0.01
Resampling (24 kHz)	0.21	0.00	0.12	0.00	0.01	0.00
Resampling (16 kHz)	8.17	0.03	6.35	0.02	3.23	0.00
Additive of Gaussian noise (30 dB)	13.07	0.10	11.06	0.09	9.04	0.01
Lowpass filtering (12 kHz)	0.41	0.13	0.22	0.00	0.04	0.00
Amplitude scaling down to 0.7	0.43	0.41	0.31	0.01	0.05	0.00

下载: 导出CSV

表 8 不同算法的平均检测性能对比(本文算法和文献[17])

Table 8 Comparison of average detection performance of different schemes (our scheme and [17])

攻击类型	本文算法			文献 [17]
攻击类型	Classical	Popular	Speech	Classical	Popular	Speech
Additive of Gaussian noise (22 dB)	0.00	0.00	0.00	0.00	0.00	0.14
Lowpass filtering (8 kHz)	0.00	0.00	0.00	1.23	0.72	0.54
Highpass filtering (50 Hz)	0.00	0.00	0.00	0.00	0.05	0.45
Echo addition (50 ms delay, 40 % decay)	0.21	0.34	0.41	1.56	0.70	3.23
Requantization (16 bit-8 bit-16 bit)	0.00	0.00	0.00	0.00	0.00	0.00
Resampling (11 025 Hz)	0.00	0.00	0.00	0.00	0.00	0.06
Resampling (6 000 Hz)	0.00	0.00	0.00	0.00	0.00	0.15
Amplitude scaling up to 1.3	0.00	0.00	0.00	0.00	0.00	0.00
Amplitude scaling down to 0.7	0.00	0.00	0.00	0.00	0.00	0.00
MP3 compression (64 kbps)	0.00	0.00	0.00	0.02	0.00	0.06
MP3 compression (48 kbps)	0.11	0.01	0.54	0.13	0.00	1.25

下载: 导出CSV
