基于显著图的弱监督实时目标检测

李阳; 王璞; 刘扬; 刘国军; 王春宇; 刘晓燕; 郭茂祖

doi:10.16383/j.aas.c180789

基于显著图的弱监督实时目标检测

doi: 10.16383/j.aas.c180789

李阳^1,,
王璞^1,,
刘扬^1,,
刘国军^1,,
王春宇^1,,
刘晓燕^1,,
郭茂祖^1,2,3,

1.
哈尔滨工业大学计算机科学与技术学院哈尔滨 150001
2.
北京建筑大学电气与信息工程学院北京 100044
3.
建筑大数据智能处理方法研究北京重点实验室北京 100044

基金项目: 国家重点基础研究发展计划(2016YFC0901902), 国家自然科学基金(61671188, 61571164, 61976071, 61871020)资助

详细信息

作者简介:
李阳：哈尔滨工业大学计算机科学与技术学院博士研究生. 2013年获得哈尔滨工业大学计算机科学与技术学院硕士学位. 主要研究方向为计算机视觉与机器学习. E-mail: liyang13@hit.edu.cn

王璞：2018年获得哈尔滨工业大学计算机科学与技术学院硕士学位. 主要研究方向为计算机视觉与机器学习. E-mail: wangpu@hit.edu.cn

刘扬：博士, 哈尔滨工业大学计算机科学与技术学院副教授. 主要研究方向为机器学习, 图像处理与计算机视觉. 本文通信作者. E-mail: yliu76@hit.edu.cn

刘国军：博士, 哈尔滨工业大学计算机科学与技术学院副教授. 主要研究方向为计算机视觉, 图像处理与模式识别. E-mail: hitliu@hie.edu.cn

王春宇：博士, 哈尔滨工业大学计算机科学与技术学院副教授. 主要研究方向为机器学习与计算生物学. E-mail: chunyu@hit.edu.cn

刘晓燕：博士, 哈尔滨工业大学计算机科学与技术学院副教授. 主要研究方向为机器学习与计算生物学. E-mail: liuxiaoyan@hit.edu.cn

郭茂祖：博士, 北京建筑大学电气与信息工程学院教授. 主要研究方向为机器学习, 数据挖掘, 生物信息学与计算机视觉. E-mail: guomaozu@bucea.edu.cn

计量
- 文章访问数: 5413
- HTML全文浏览量: 1767
- PDF下载量: 652
- 被引次数: 0
出版历程
- 收稿日期: 2018-11-27
- 录用日期: 2019-06-24
- 网络出版日期: 2020-01-16
- 刊出日期: 2020-03-06

Weakly Supervised Real-time Object Detection Based on Saliency Map

LI Yang^1
,,
WANG Pu^1
,,
LIU Yang^1
,,
LIU Guo-Jun^1
,,
WANG Chun-Yu^1
,,
LIU Xiao-Yan^1
,,
GUO Mao-Zu^{1,2,3
,}

1.
School of Computer Science and Technology, Harbin Institute of Technology, Harbin 150001
2.
School of Electrical and Information Engineering, Beijing University of Civil Engineering and Architecture, Beijing 100044
3.
Beijing Key Laboratory of Intelligent Processing for Building Big Data, Beijing 100044

Funds: Supported by National Key Research and Development Program of China (2016YFC0901902) and National Natural Science Foundation of China (61671188, 61571164, 61976071, 61871020)

摘要

摘要: 深度卷积神经网络(Deep convolutional neural network, DCNN)在目标检测任务上使用目标的全标注来训练网络参数, 其检测准确率也得到了大幅度的提升. 然而, 获取目标的边界框(Bounding-box)标注是一项耗时且代价高的工作. 此外, 目标检测的实时性是制约其实用性的另一个重要问题. 为了克服这两个问题, 本文提出一种基于图像级标注的弱监督实时目标检测方法. 该方法分为三个子模块: 1)首先应用分类网络和反向传递过程生成类别显著图, 该显著图提供了目标在图像中的位置信息; 2)根据类别显著图生成目标的伪标注(Pseudo-bounding-box); 3)最后将伪标注看作真实标注并优化实时目标检测网络的参数. 不同于其他弱监督目标检测方法, 本文方法无需目标候选集合获取过程, 并且对于测试图像仅通过网络的前向传递过程就可以获取检测结果, 因此极大地加快了检测的速率(实时性). 此外, 该方法简单易用; 针对未知类别的目标检测, 只需要训练目标类别的分类网络和检测网络. 因此本框架具有较强的泛化能力, 为解决弱监督实时检测问题提供了新的研究思路. 在PASCAL VOC 2007数据集上的实验表明: 1)本文方法在检测的准确率上取得了较好的提升; 2)实现了弱监督条件下的实时检测.
- 弱监督 /
- 实时目标检测 /
- 显著图 /
- 伪标注 /
- 深度卷积神经网络
Abstract: Deep convolutional neural network (DCNN) trains model parameters by using object bounding-box annotations in object detection task, and its detection accuracy has been greatly improved. However, bounding-box annotations are very expensive and time-consuming. In addition, the real-time performance of object detection is another important problem that restricts its practicality. To solve these two problems, this paper proposes a new weakly supervised real-time object detector with image-level labels. The proposed method includes three sub-modules: 1) firstly, producing class-specific saliency maps based on a classification network and the back-propagation process, which provides object localization clues; 2) then, generating pseudo-annotations (pseudo-bounding-box) based on class-specific saliency maps; 3) finally, treating the pseudo annotations as ground-truth and optimizing the parameters of our real-time object detection network. Different from other weakly supervised object detection methods, our method avoids the computing process for obtaining object candidates. And we obtain object detection results of test images by feed-forward process, thus our method greatly speeds up the detection process (real-time). In addition, our method is simple and easy to use; for unknown class objects, we only need to train the classification and detection networks. So our method has a strong generalization ability and provides a new idea for weakly supervision real-time detection problem. Extensive experiments on PASCAL VOC 2007 benchmark show that: 1) the proposed method achieves a good improvement on detection accuracy; 2) it realizes real-time detection under weakly supervised condition.
- Weakly supervised /
- real-time object detection /
- saliency map /
- pseudo-annotations /
- deep convolutional neural network (DCNN)

HTML全文

图 1 弱监督实时目标检测方法结构图

Fig. 1 Pipeline for weakly supervised real-time object detection

下载: 全尺寸图片幻灯片

图 2 类别显著图

Fig. 2 Class-specific saliency maps

下载: 全尺寸图片幻灯片

图 3 二值化类别显著图以及相应的伪标注

Fig. 3 Binarization class-specific saliency maps and the corresponding pseudo-bounding-boxes

下载: 全尺寸图片幻灯片

图 4 $4\times 4$及$8\times 8$的特征单元和相对应的目标基检测框

Fig. 4 Feature map cells for $4\times 4$ and $8\times 8$ and its corresponding object default bounding-boxes

下载: 全尺寸图片幻灯片

图 5 不同阈值设定下20个类别的目标检测准确率

Fig. 5 Object detection precision for 20 categories under different thresholds

下载: 全尺寸图片幻灯片

图 6 PASCAL VOC 2007测试集上的成功检测样例

Fig. 6 Successful detection examples on PASCAL VOC 2007 test set

下载: 全尺寸图片幻灯片

图 7 PASCAL VOC 2007 测试集上的失败检测样例

Fig. 7 Unsuccessful detection examples on PASCAL VOC 2007 test set

下载: 全尺寸图片幻灯片

表 1 二值化类别显著图的阈值设置(PASCAL VOC数据集20个类别)

Table 1 Thresholds of the binarization class-specific saliency maps (20 categories for PASCAL VOC dataset)

类别	阈值	类别	阈值	类别	阈值
Plane	0.7	Cat	0.4	Person	0.5
Bike	0.7	Chair	0.6	Plant	0.7
Bird	0.5	Cow	0.5	Sheep	0.5
Boat	0.8	Diningtable	0.3	Sofa	0.5
Bottle	0.8	Dog	0.3	Train	0.7
Bus	0.6	Horse	0.3	TV	0.8
Car	0.6	Motorbike	0.5

下载: 导出CSV

表 2 PASCAL VOC 2007测试数据集的目标检测准确率(%)

Table 2 Object detection precision (%) on PASCAL VOC 2007 test set

方法	Bilen^[11]	Cinbis^[7]	Wang^[32]	Teh^[17]	WSDDN^[10]	WSDDN_Ens^[10]	WCCN^[9]	MELM^{[12, 14]}	PCL^[13]	本文 (07数据集)	本文 (07+12数据集)
mAP	27.7	30.2	31.6	34.5	34.8	39.3	42.8	47.3	48.8	33.9	39.3
Plane	46.2	39.3	48.9	48.8	39.4	46.4	49.5	55.6	63.2	54.5	54.2
Bike	46.9	43.0	42.3	45.9	50.1	58.3	60.6	66.9	69.9	52.9	60.0
Bird	24.1	28.8	26.1	37.4	31.5	35.5	38.6	34.2	47.9	30.0	41.9
Boat	16.4	20.4	11.3	26.9	16.3	25.9	29.2	29.1	22.6	15.2	20.7
Bottle	12.2	8.0	11.9	9.2	12.6	14.0	16.2	16.4	27.3	7.8	11.4
Bus	42.2	45.5	41.3	50.7	64.5	66.7	70.8	68.8	71.0	47.3	55.9
Car	47.1	47.9	40.9	43.4	42.8	53.0	56.9	68.1	69.1	44.5	49.2
Cat	35.2	22.1	34.7	43.6	42.6	39.2	42.5	43.0	49.6	62.5	71.3
Chair	7.8	8.4	10.8	10.6	10.1	8.9	10.9	25.0	12.0	9.4	10.5
Cow	28.3	33.5	34.7	35.9	35.7	41.8	44.1	65.6	60.1	17.6	23.2
Table	12.7	23.6	18.8	27.0	24.9	26.6	29.9	45.3	51.5	39.3	48.5
Dog	21.5	29.2	34.4	38.6	38.2	38.6	42.2	53.2	37.3	48.9	54.5
Horse	30.1	38.5	35.4	48.5	34.4	44.7	47.9	49.6	63.3	45.7	52.1
Motorbike	42.4	47.9	52.7	43.8	55.6	59.0	64.1	68.6	63.9	49.9	56.4
Person	7.8	20.3	19.1	24.7	9.4	10.8	13.8	2.0	15.8	17.2	15.0
Plant	20.0	20.0	17.4	12.1	14.7	17.3	23.5	25.4	23.6	15.7	17.6
Sheep	26.6	35.8	35.9	29.0	30.2	40.7	45.9	52.5	48.8	18.4	23.3
Sofa	20.6	30.8	33.3	23.2	40.7	49.6	54.1	56.8	55.3	29.3	42.5
Train	35.9	41.0	34.8	48.8	54.7	56.9	60.8	62.1	61.2	43.7	47.6
TV	29.6	20.1	46.5	41.9	46.9	50.8	54.5	57.1	62.1	28.2	30.4

下载: 导出CSV

表 3 PASCAL VOC 2007测试数据集上的目标检测速度(FPS)及检测平均准确率

Table 3 Object detection speed (FPS) and detection mean average precision on PASCAL VOC 2007 test set

评价指标及数据	FPS	mAP	数据集
$30\,$HzDPM^[24]	30	26.1	07
Fast R-CNN^[1]	0.5	70.0	07+12
Faster R-CNN^[4]	7	73.2	07+12
YOLO_VGG^[39]	21	66.4	07+12
Fast_YOLO^[39]	155	52.7	07+12
SSD^[3]	46	68.0	07
WSDDN_Ens^[10]	0.5	39.3	07
WCNN^[9]	−	42.8	07
MELM^{[12, 14]}	−	47.3	07
PCL^[13]	1.4	48.8	07
本文方法	45	39.3	07+12

下载: 导出CSV

表 4 不同二值化阈值对于检测准确率(%)的影响

Table 4 The influence of different binarization thresholds on the detection precision (%)

阈值	0.3	0.4	0.5	0.6	0.7	表1
mAP	26.6	28.7	30.3	29.4	26.7	33.9
Plane	30	39.8	45.5	47.7	51.1	54.5
Bike	45.8	37.9	51.6	53	54.2	52.9
Bird	22.8	30.8	32	29.2	26.9	30.0
Boat	6.3	5.2	8.2	10.5	15.1	15.2
Bottle	2.5	2.8	4.1	5.3	5.9	7.8
Bus	42.1	44.3	48.6	50	49.7	47.3
Car	32.9	36.9	39.5	44.6	44.7	44.5
Cat	59	63	58.5	47.6.	23.8	62.5
Chair	1	1.8	1	9.5	1.2	9.4
Cow	18.6	16.1	22.5	16.5	15.6	17.6
Table	40.4	36.5	38.1	29.9	24	39.3
Dog	51.8	47.8	36.7	25.1	7.6	48.9
Horse	41.6	44.5	44.2	40	31.3	45.7
Motorbike	47.9	51	55.1	51.3	49	49.9
Person	9.6	12.4	15.3	12.5	9.2	17.2
Plant	11.1	11.6	11.3	10.7	17.1	15.7
Sheep	12.7	14.4	20.7	17.7	15.6	18.4
Sofa	25.2	29	27.9	31.8	26.6	29.3
Train	26	28.8	34.6	39.6	42.9	43.7
TV	5.2	10	10.7	15	22.2	28.2

下载: 导出CSV

表 5 在不同二值化阈值下, 通过文献[23]的方法生成的测试集检测结果(mAP)与本文方法的对比

Table 5 Under different binarization thresholds, the detection results (mAP) of test set generated by [23] and our method

阈值	文献 [23] (%)	本文方法 (%)	阈值	文献 [23] (%)	本文方法 (%)
0.3	16.7	26.6	0.6	16.1	29.4
0.4	17.5	28.7	0.7	13.7	26.7
0.5	17.5	30.3	表1	18.5	33.9

下载: 导出CSV
